Unscrew the tht~e bolts of the support on the mounting plate.
The three nuts at the rear of this plate are crimped on.
- Unscrew the fOl.Ir bolts securi ng the motor to its support.
Pullout the pir securing the p{ni~n on the motor shaft (pin dia.
3
mm).
Replace the motlr and proceed vice versa.
Unscrew the support from the wiring plate.
Rep
1
ace the hea,1:erand proceed vice versa.
Remove the two :iecuring rings and then pu
11
out the small ax
1
e
from the switch eyelet.
Press the lever into upright position.
Remove the two ruts securing the switch to its support.
- After·replacing the switch, tighten the two nuts on the support.
Reset the axle and the two bushes in the eyelet and fit the two
securing rings.
