AEG TP7050TW - Quick Guide

Programme Spun at / residual humidity
Drying time
1)
Energy
consump-
tion
2)
1000 rpm / 60% 179 min. 2,60 kWh
Bügeltrocken (Iron
Dry)
1400 rpm / 50% 113 min. 1,47 kWh
1000 rpm / 60% 135 min. 1,79 kWh
Baumwolle (Cotton) Eco 4 kg
Schranktrocken (Cup-
board Dry)
1400 rpm / 50% 86 min. 1,14 kWh
1000 rpm / 60% 102 min. 1,38 kWh
Mischgewebe (Synthetics) 3,5 kg
Schranktrocken (Cup-
board Dry)
1200 rpm / 40% 58 min. 0,71 kWh
800 rpm / 50% 72 min. 0,90 kWh
1)
For partial loads, the cycle time is shorter and appliance uses less energy.
2)
Improper ambient temperature and/or poorly centrifuged laundry can prolong cycle time and increase
the energy consumption.
14. QUICK GUIDE
14.1 Daily use
1 2
3
5
4
1. Push the On/Off button to turn on
the appliance.
2. Use the programme dial to set the
programme.
www.aeg.com20
