3. PRODUCT DESCRIPTION
1 2
5
3
4
6
7
8
9
1
Water container
2
Control panel
3
Appliance door
4
Filter
5
Rating plate
6
Airflow slots
7
Heat Exchanger lid
8
Heat Exchanger cover
9
Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
4. CONTROL PANEL
1
789 6 5
3
4
2
1
Programme knob and RESET
switch
2
Display
3
Zeit (Time Dry) touch button
4
Zeitvorwahl (Delay Start) touch
button
5
Start/Pause touch button
6
Knitterschutz (Extra Anticrease)
touch button
7
Reverse Plus touch button
8
Indicator: clean filter, drain
water container, check
condenser
9
On/Off button
