14 TECHNICAL DETAILS
Standard Digital Enhanced Cordless (DECT)
Frequency range 1.88 to 1.9 GHz (bandwidth = 20 MHz)
Channel bandwidth 1.728 MHz
Operating range Up to 300m outdoors; Up to 50m indoors
Operating time Standby: 200 hours, Talking: 14 hours
Battery charge time: 15 hours
Temperature range Operating 0° C to 40° C,
Storage -20° C to 60° C
Electrical power Ten Pao - S003IB0600045 / S003IV0600045
100-240VAC 50/60Hz 50mA, 6VDC 450mA
VTPL – VT04EEU06045 / VT04EUK06045
100-240VAC 50/60Hz 150mA, 6VDC 450mA
Ruijing - RJ-AS060450B001 /
RJ-AS060450E002 100-240VAC
50/60Hz 150mA, 6VDC 450mA
Battery information:
Type Ni-MH (Rechargeable battery)
Voltage Rating 600mAh, 1.2V AAA Size
Port specifications:
The port (connected to the mains power supply) is a SELV port with
respect to EN41003.
The port (connected to the telephone line) is a TNV port with respect
to EN41003.
15 CE DECLARATION
This product is in compliance with the essential requirements
and other relevant provisions of the R&TTE directive 1999/5/EC.
The Declaration of conformity can be found on:
www.aegtelephones.eu
