RevC 07/15/13 Page 32
INFINITY INSTALLATION REQUIREMENTS
Pre-installation check
Check the following before installation:
Fuel pressure (must be set to factory specs)
Spark plugs (recommend starting with new plugs)
Ignition timing (must be set to factory specs)
Fuel filter (recommend starting with new filter)
Fuel injectors (must be in known good working condition)
Spark plug wires
Distributor cap and rotor (if applicable)
See included fuel system recommendations before starting
Clean bare-metal ground connections for universal applications
13.8V (10V absolute minimum) main relay power distribution for universal
applications
Universal Wiring Options
30-3702 - Harness, Infinity-10 Mini Lead (sold separately)
30-3701 - Connector Kit, Infinity-10 (sold separately)
Plug and Play Wiring Options
30-3500 - Harness Kit, Infinity Supra (sold separately)
Accessories
30-3600 - O2 Sensor Ext Harness, Infinity
30-3601 - IP67 Comms Cable, Infinity
30-3602 - IP67 Logging Cable, Infinity
Molex Crimp Tools (can be purchased from http://www.newark.com)
o Molex Part No: 63811-4200 (recommended crimp tool)
http://www.newark.com/molex/63811-4200/hand-crimp-
tool/dp/81H6890?Ntt=63811-4200
o Molex Part No: 63811-1000 (less expensive alternative to 4200)
http://www.newark.com/molex/63811-1000/hand-crimp-
tool/dp/85C2464?Ntt=63811-1000
