AEM SM95-766 AA95-766 User Manual

AA95-766 Single Channel Audio Controller
SM95-766 Installation and Operation Manual
June 20, 2012 Rev: 3.00 Page 1-4
ENG-FORM: 800-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
Bi-directional Signals:
Quantity One NAT ICS tie channel
Audio level 0.34 Vrms
Impedance 1.8 kΩ ±10%
Circuitry Type Single ended
Miscellaneous:
Annunciators Green LED will light for transmit operation
1.4.2 Physical Specifications
Height 1.91" (48.5 mm) max.
Depth 7.05” (179.1 mm) max. behind panel
Width 5.78" (146.8 mm) max.
Weight 2.1 lbs (1.0kg) max. excluding harness and mating
connectors
Mounting Standard Dzus rails
Connectors One male 50-pin and one male 37-pin D-min connector
1.4.3 Environmental Specifications
Operating Temp -40q C. to +70q C
Survival Temp -55q C. to + 85q C
Vibration/Shock DO-160B category “P”, panel mounting 6g.
Humidity 95% Non-condensing
Altitude 35,000 feet
End of Section 1.0

AEM SM95-766 AA95-766 Specifications

General

Brand	AEM
Model	SM95-766 AA95-766
Category	Recording Equipment
Language	English
