AM450e User Manual
AEMULUS 9
Pin
Signal Name
1
Left Open
2
Left Open
3
Left Open
4
Left Open
5
Left Open
6
Left Open
7
Left Open
8
Channel 1, Sense-Low
9
Channel 1, Sense-High
10
Channel 1, Guard
11
Channel 0, Sense-Low
12
Channel 0, Sense-High
13
Channel 0, Guard
14
Left Open
15
Left Open
16
Left Open
17
Left Open
18
Left Open
19
Left Open
20
Channel 1, Force-Low
21
Channel 1, Guard
22
Channel 1, Force-High
23
Channel 0, Force-Low
24
Channel 0, Guard
25
Channel 0, Force-High
Table 2: Analog Output Pin-out (Without External High Current Module)
If AM450e is used without the external high current module, pins 1-7 and
pins 14-18 must be left open. Do not connect these pins to device-under-
test (DUT). Failing to do this may cause unexpected test failures or
damages.
WARNING
