AM450e User Manual
AEMULUS 10
Pin
Signal Name
1
No Connect
2
No Connect
3
No Connect
4
No Connect
5
No Connect
6
No Connect
7
No Connect
8
Channel 1, Sense-Low
9
Channel 1, Sense-High
10
Channel 1, Guard
11
Channel 0, Sense-Low
12
Channel 0, Sense-High
13
Channel 0, Guard
14
No Connect
15
No Connect
16
No Connect
17
No Connect
18
No Connect
19
No Connect
20
Channel 1, Force-Low
21
Channel 1, Guard
22
Channel 1, Force-High
23
Channel 0, Force-Low
24
Channel 0, Guard
25
Channel 0, Force-High
Table 3: Analog Output Pin-out (With External High Current Module)
