1. Set your Z-Wave controller into pairing mode.
2. Press the Action Button on the Nano Dimmer, the green LED (non-secure indication) will blink to indicate the
Nano Dimmer is entering into pairing mode.
3. If the Nano Dimmer has been successfully added to your Z-Wave network, its RGB LED will be solid. If the
pairing was unsuccessful, the red LED will be on for 2 seconds and then remain a colourful gradient, repeat the
instructions above from step 1.
With your Nano Dimmer now working as a part of your smart home, you’ll be able to configure it from your home
control software/phone application. Please refer to your software’s user guide for further instructions on configuring
Nano Dimmer to your needs.
The colour of RGB LED will change according to the output load power level:
Version LED indication Output (W)
US
Green [0W, 48W)
Yellow [48W, 96W)
Red [96W, 144W)
AU
Green [0W, 92W)
Yellow [92W, 184W)
Red [184W, 276W)
EU
Green [0W, 92W)
Yellow [92W, 184W)
Red [184W, 276W)
Adding your Nano Dimmer to Z-Wave network using the External Switch.
Using this method, you will never have to remove the external switch to get to your Nano Dimmers button to perform
an inclusion.
1. Set your Z-Wave controller into pairing mode
2. Toggle the External Switch once (If using a momentary push button tap the button once), the green LED (non-
secure indication) will blink to indicate the Nano Dimmer is entering into pairing mode.
3. If the Nano Dimmer has been successfully added to your Z-Wave network, its RGB LED will be solid. If the
pairing was unsuccessful, the red LED will be on for 2 seconds and then remain a colourful gradient, repeat the
instructions above from step 1.
Removing Nano Dimmer from a Z-Wave network using the Internal Button.
Your Nano Dimmer can be removed from your Z-Wave network at any time. You’ll need to use your Z-Wave network’s
main controller. To set your Z-Wave controller/gateway into removal mode, please refer to the respective section
within your controller instruction manual.
1. Set your Z-Wave controller into removal mode.
2. Press the Action Button on the Nano Dimmer.
3. If the Nano Dimmer has been successfully removed from your Z-Wave network, its RGB LED will remain
colourful gradient. If the removal was unsuccessful, the RGB LED will still be solid (following the state of the output
load), repeat the instructions above from step 1.
Removing your Nano Dimmer to Z-Wave network using the External Switch.
To Next Page
