5.1 SERVICE INFORMATION
5.2 TROUBLESHOOTING
5.3 CAMSHAFT ASS’Y REMOVAL
5.4 CYLINDER HEAD REMOVAL
5.5 CYLINDER HEAD INSTALLATION
5.1 SERVICE INFORMATION
GENERAL
This section describes the maintenance of cylinder head, valves, camshaft and the other parts.
The engine must be removed from the frame to service cylinder head.
Camshaft lubrication oil is fed to the cylinder head through an oil orifice in the engine case.
Before installing the cylinder head be sure the orifice is not clogged and the gasket, O-ring and
dowel pins are in place.
SPECIFICATIONS
ITEM STANDARD SERVICE LIMIT
Cylinder compression 12±0.5 kg/cm
2
---------
Cam lobe height IN
EX
25.965/27.195
25.810/27.20
25.57/26.7
25.40/26.80
Rocker arm I.D. 10.000-10.018 10.10
Rocker arm shaft O.D. 9.972-9.987 9.91
Valve spring free length IN
EX
32.3
35.0
31.2
34.1
Valve stem O.D. IN
EX
4.975-4.990
4.955-4.970
4.90
4.90
Valve guide I.D. IN/EX 5.000-5.012 5.30
Stem-to-guide clearance IN
EX
0.010-0.037
0.030-0.057
0. 08
0.10
Valve seat width IN
EX
1. 0
1.0
1. 8
1.8
TORQUE VALUES
Cylinder head bolts 8~12 N.m (5.9~8.9 lbs.ft)
Camshaft holder flange nuts 20~24 N.m (14.8~17.8 lbs.ft)
Tappet adjusting nut 9~12 N.m (6.6~8.9 lbs.ft)
5.2 TROUBLE SHOOTING
