Remove the mounting bolts and nuts from the
front fender and footrest plate.
10.3 EXHAUST PIPE REMOVAL
You must wait at least 15 minutes after turn off
the engine. You need to remove the seat, rear
fender and footrest plate, before you take off the
exhaust pipe. Unscrew the two exhaust pipe
bolts that fixed with engine.
NOTE: Do not service the exhaust pipe while
they are hot.
Remove the exhaust pipe bolts mounting on the
frame below the rear fender.
Remove the exhaust pipe carefully.
10.4 EXHAUST PIPE INSTALLATION
Installation is the reverse order of removal.
Torque: Exhaust muffler bolts 30 N.m (22 lbs.ft)
NOTE: After installation, check entire system to
make sure that there are no exhaust leaks.
