5.7 Insert-loop pre/post EQ
The insert-loop (without/pre od with/post eq) is
an in-/output on a stereo-socket to link di erent
e ect-devices (EQ, compressor etc.) in serial mode
with tip = send (input) and ring = return (output).
This con guration allows several more applications,
such as:
1. use as additional line-output
2. use as additional line-input
3. link between two or more AER-amps with
insert-feature (AG8, Domino, Compact ClassicPro)
For each of these applications you’ll need the ap-
propriate cable connection, e.g. use as line-output:
stereo-jack (tip and ring = hot, sleeve = ground) to
mono-jack.
In link operation it is assured, that the signals of all
connected amps are hearable on all devices, even
with di erent e ect settings. You just have to be
aware, that the di erent levels depend on each
other.
