5
COMPONENTI PRINCIPALI MAIN COMPONENTS COMPOSANTS PRINCIPAUX HAUPTBESTANDTEILE
1 - Mobile di copertura 1 - Cabinet 1 - Meuble 1 - Verkleidungsgehäuse
2 - Scheda elettronica 2 - Electronic control 2 - Platine électronique 2 - Steuerplatine
3 - Gruppo ventilante 3 - Fan section 3 - Groupe de ventilation 3 - Lüftereinheit
4 - Ricevitore 4 - Receiver 4 - Recepteur 4 - Empfänger
5 - Scambiatore di calore 5 - Heat exchanger 5 - Echangeur de chaleur 5 - Wärmetauscher
6 - Filtro aria 6 - Air filter 6 - Filtre 6 - Luft filter
A
U
X
5
1
3
6
2
4
FA
MOD
C
°C
TELECOMANDO
I. R. REMOTE CONTROL
TELECOMMANDE
I. R.- FERNBEDIENUNG
UNITÀ INTERNA
INDOOR UNIT
UNITE INTERIEURE
INNENEINHEIT
24°
32°
16°
PANNELLO COMANDI
CONTROL PANEL
PANNEAU DE COMMANDE
KABELFERNBEDIENUNG
