10
English
The cassette fan coils are sent in standard packaging made of
foam polystyrene and cardboard.
We would like to thank you for having purchased our cassette type fan coil "FCA" Aermec.
It is made with high quality material, in strict compliance to "FCA" safety norms and is easy to use and is long lasting.
PURPOSE OF THE MACHINE
The cassette type fancoil unit is a terminal for the treatment of
air in a room regardless of whether it is summer or winter.
The unit is ceiling-mounted with the possibility of treating fresh
outside air and sending treated air to an adjacent rooms.
CHARACTERISTICS
- Ventilating axial-centrifuge 4-speed unit.
- Very quiet operation.
- Great well-designed grille appearance.
- Grille dimensions respect standard suspending ceiling
panel sizes (600x600 mm), with single-panel units (single)
and higher power for two panels (twin).
- Continuous fan functioning to avoid the air becoming stra-
tified.
- Possibility of outside air being brought in.
It is also possible to cool one or two adjacent rooms.
- Easy to install and maintain.
- Electrostatically pre-charged, self-bearing filter, featuring
great efficiency and low pressure drops Fire Resistance
Class 2 (UL900).
- Air filter easy to remove and clean with vacuum cleaner.
- Standard hot/cold battery valve. .
- Full compliance with accident protection regulations.
AVAILABLE VERSIONS AND SIZES
The FCA and FCA-R fancoil units are available in:
5 sizes for two-pipe systems
FCA 32 FCA 32 R1 Mono
FCA 36 FCA 36 R1 Mono
FCA 42 FCA 42 R1 Mono
FCA 62 FCA 62 R1 Mono
FCA 82 FCA 82 R1 Twin
FCA 122 FCA 122 R1 Twin
5 sizes for four-pipe systems
FCA 34 FCA 34 R1 Mono
FCA 38 FCA 38 R1 Mono
FCA 44 FCA 44 R1 Mono
FCA 64 FCA 64 R1 Mono
FCA 84 FCA 84 R1 Twin
FCA 124 FCA 124 R1 Twin
MINIMUM AVERAGE WATER TEMPERATURE
Dry bulb temperature °C
21 23 25 27 29 31
15 3 3 3 3 3 3
17 3 3 3 3 3 3
Wet bulb temperature °C 19 3 3 3 3 3 3
21 6 5 4 3 3 3
23 - 8 7 6 5 5
DESCRIPTION OF THE UNIT
OPERATIONAL LIMITS
PACKAGING
OPERATION
The assembly site must be chosen in such a way that the
maximum and minimum ambient temperature limits Ta are
respected 0°C < Ta < 45°C ; R.H. < 85%.
The FCA cassette fan coils are powered with a voltage of 230
V monophase at 50 Hz and ground connection, in any case
the power of the line must remain within the limit of ±10%
with respect to the nominal value.
If the fan coil is working in cold continuous mode inside an
environment where the relative humidity is high, condensa-
te might form on the air delivery. Said condensate might be
deposited on the floor and on any objects underneath. To
avoid condensate on the external structure of the apparatus
with the fan in operation, the average temperature of the
water must not be lower than the limits shown in the table
below, that depend on the thermo-hygrometric condition of
the air in the environment. The above limits refer to fan move-
ment at minimum speed.
The use of water at high temperatures could cause squeaking
due to the different thermal expansions of the elements (pla-
stics and metals), this does not however cause damage to the
unit if the maximum operating temperature is not exceeded.
Maximum water input temperature 80 [°C]
Maximum operating temperature 8 [bar]
Maximum height off the ground 3 [m]
FCA: usage instructions are contained in the manuals supplied
with the command panels.
FCA-R: usage instructions are contained in the manual FCA-R
directions for use.
