Motorised louvre
From the remote control, the swing key will put the louvre into motion and this will continue to
rotate until the next (stop) command. The louvre also stops when the ventilation stops (e.g.
because the setting has been reached).
Ambient probe
The reading of the temperature by means of the ambient probe is continuous with the ventilation in
operation. If the machine is not operating, with thermostat-controlled heating ventilation, after
three minutes the machine opens the water valve (Y1 if 2 pipes or Y2 if 4 pipes) and, after waiting
2’40’’ for the complete opening of the valve, activates a period of ventilation (30’’) and then reads
the temperature of the ambient probe. If the thermostat continues not to give the enabling signal to
switch on, the next reading takes place after 8 minutes (30’’ ventilation and subsequent reading).
After which the reading is taken every fifteen minutes.
Thermostat-controlled heating ventilation: pre-heating of coil
If thermostat-controlled heating ventilation is activated, the fan is not turned on immediately when
the envisaged conditions occur; it waits for a period of time. This allows the solenoid valve to
completely open and make the heating water flow into the coil. The valve opening time is around 2
minutes and 40 seconds, and this is also the value of the delay before the fan is activated.
3’
Y1 (Y2)
Ventilatore
Consenso
termostato
Heating fan timing (without electric heater)
Following the first activation of the fan, the fan inhibition time is calculated automatically and
depends on how long the valve had been closed for, and it can therefore vary from a minimum of 0’
00’’ to a maximum of 3’.
