AERMEC FCL Series - Troubleshooting and Diagnostics; Autotest Procedures

58
Autotest
This section shows the two autotest procedures: from infrared receiver and wired panel.
It is possible to activate the autotest mode by powering the machine, keeping the AUX key pressed
down for about 5 seconds. In this case, the board makes two beeps by means of the buzzer, and is
positioned at step 0. With reference to the table, each time the AUX key is pressed again it is
necessary to follow the indications given in the “OPERATION” column and check that the LED and
the relay outputs correspond with the data in the table
Step TEST OPERATION LED FCL LOADS ACTIVE
RELAYS
0 Dip-switch SW1-
SW2
Wait for version
visualisation (if
envisaged by the
software)
(*) OFF OFF
1 Presence of SA probe
- Indicated loads
Wait for the red
LED to switch on
RED V3
Y2
O3
O4
O7
2 Presence of SW probe
- Indicated loads
Wait for the yellow
and blue LEDs to
switch on
YELLOW
AND BLUE
V1
Y1
O1
O6
3 Presence of SW/SR2
probe
- Indicated loads
Wait for the red LED
to switch on
RED V2
Y2
O2
O4
4 Presence of SAE
probe
- Indicated loads
Wait for the yellow
LED to switch on
YELLOW V3 O3
5 Trimmer PT1
precision
- Indicated loads
Turn the PT1 trimmer
to the central position
until the red LED
switches on
RED V3
Y2
MA
Y1
RE
O3
O4
O5
O6
O7
O8
6 - Receiver circuit
- Indicated loads
Set ON from remote
control (the board
emits a beep)
YELLOW V1 O1
7 - Eeprom
- Indicated loads
Wait for the LED to
turn red
RED V2 O2
8 - External contact
OPEN
- Indicated loads
Open External
Contact (C1 input)
YELLOW V3 O3
9 - External contact
CLOSED
- Indicated loads
Close External
Contact (C1 input)
RED Y2 O4
10 - Contact AL1 open
- Indicated loads
Open contact AL1
(C1 input)
YELLOW MA O5
11 - Contact AL1 closed
- Indicated loads
Close contact AL1
(C1 input)
RED V1 O1
Note: (*) Displays the Software version.
Table
