14
IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 640 640 799 799 954 954 1105 1105 1256 1256 1330 1330
17 873 719 905 905 973 973 1107 1107 1258 1258 1333 1333
19 1358 726 1355 902 1352 1077 1353 1255 1382 1382 1398 1398
21 1866 899 1862 1076 1858 1251 1854 1426 1853 1512
23 2411 1068 2405 1244 2401 1420 2397 1506
5
15 522 522 700 700 866 866 1027 1027 1183 1183 1261 1261
17 601 580 729 729 868 868 1028 1028 1186 1186 1264 1264
19 1072 599 1075 776 1107 963 1168 1158 1249 1249 1294 1294
21 1627 794 1624 970 1624 1146 1624 1322 1632 1413
23 2187 970 2187 1148 2179 1322 2179 1410
7
15 306 306 550 550 745 745 921 921 1088 1088 1170 1170
17 306 306 552 552 747 747 924 924 1091 1091 1171 1171
19 506 357 699 603 845 827 979 979 1111 1111 1179 1179
21 1265 642 1268 819 1306 1007 1366 1203 1401 1301
23 1910 854 1908 1030 1906 1205 1902 1291
13
3
15 476 476 639 639 796 796 949 949 1100 1100 1175 1175
17 514 514 641 641 798 798 951 951 1103 1103 1178 1178
19 936 540 933 714 956 896 1012 1012 1106 1106 1181 1181
21 1453 720 1450 896 1447 1069 1445 1242 1451 1332
23 1997 891 1995 1067 1989 1240 1987 1327
5
15 324 324 528 528 702 702 866 866 1026 1026 1105 1105
17 325 325 528 528 703 703 868 868 1028 1028 1107 1107
19 509 359 638 577 762 762 886 886 1030 1030 1109 1109
21 1159 599 1159 774 1183 956 1235 1147 1265 1242
23 1744 787 1740 961 1736 1134 1736 1222
7
15 154 154 308 308 562 562 751 751 925 925 1008 1008
17 154 154 308 308 562 562 754 754 926 926 1009 1009
19 159 159 310 310 569 569 755 755 928 928 1012 1012
21 588 374 754 603 892 821 1020 1020 1080 1080
23 1377 644 1377 818 1404 1002 1426 1096
15
3
15 304 304 477 477 638 638 794 794 945 945 1022 1022
17 305 305 477 477 639 639 796 796 948 948 1023 1023
19 445 334 538 533 650 650 797 797 949 949 1026 1026
21 1001 536 998 708 1015 887 1060 1060 1091 1091
23 1555 713 1553 887 1548 1058 1547 1144
5
15 124 124 335 335 531 531 703 703 866 866 947 947
17 124 124 335 335 532 532 705 705 868 868 948 948
19 125 125 337 337 533 533 706 706 871 871 949 949
21 558 363 677 574 794 781 911 911 971 971
23 1246 595 1246 768 1261 946 1280 1039
7
15 25 25 154 154 321 321 570 570 756 756 843 843
17 25 25 154 154 321 321 571 571 758 758 845 845
19 25 25 154 154 322 322 573 573 759 759 846 846
21
160 160 332 332 589 589 766 766 849 849
23 661 383 813 603 944 815 1007 920
COOLING CAPACITY - FCLI 32 / FCLI34
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
FCLI 32 / FCLI34
Qv [m
3
/h] k (Pc) k (Ps)
Speed V3
600 1 1
Speed V2 410 0.77 0.82
Speed V1 300 0.61 0.65
COOLING CAPACITY CORRECTION FACTORS
