IFCLITY1106 - 5773010_01
COOLING CAPACITY - FCLI 42
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
FCLI 42
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0.82 0.75
Speed V2 360 0.64 0.58
Speed V1 260 0.50 0.44
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 3173 2662 3159 3029 3173 3173 3272 3272 3580 3580 3736 3736
17 4094 2648 4086 3022 4078 3391 4069 3758 4057 4057 4061 4061
19 5089 2627 5077 3002 5065 3373 5052 3742 5040 4105 5032 4287
21 6143 2973 6126 3346 6110 3714 6093 4082 6089 4265
23 7270 3308 7262 3685 7237 4051 7229 4235
5
15 2737 2420 2800 2800 2918 2918 3122 3122 3436 3436 3592 3592
17 3711 2441 3703 2813 3691 3180 3707 3556 3748 3748 3790 3790
19 4719 2430 4711 2805 4703 3177 4695 3548 4686 3913 4670 4091
21 5789 2786 5772 3158 5764 3530 5752 3898 5748 4082
23 6932 3131 6916 3502 6900 3871 6891 4055
7
15 2194 2108 2398 2398 2622 2622 2924 2924 3252 3252 3416 3416
17 3156 2152 3150 2523 3201 2911 3303 3303 3439 3439 3529 3529
19 4275 2201 4267 2575 4259 2946 4242 3310 4250 3681 4259 3870
21 5377 2576 5361 2946 5353 3316 5345 3686 5336 3866
23 6538 2931 6529 3305 6513 3674 6505 3857
7
3
15 2463 2273 2497 2497 2633 2633 2947 2947 3258 3258 3411 3411
17 3391 2273 3382 2643 3371 3010 3368 3368 3428 3428 3473 3473
19 4382 2256 4374 2631 4365 3002 4349 3365 4345 3731 4333 3908
21 5435 2607 5419 2977 4349 3365 5394 3712 5390 3895
23 6562 2946 6554 3320 6538 3688 6529 3871
5
15 2033 2025 2211 2211 2469 2469 2794 2794 3114 3114 3269 3269
17 2947 2046 2935 2413 2975 2795 3060 3060 3190 3190 3297 3297
19 3975 2052 3966 2425 3962 2796
3950 3160
3946 3526 3954 3714
21 5048 2414 5040 2787 5032 3156 5015 3520 5011 3702
23 6192 2763 6184 3135 6167 3503 6159 3685
7
15 1584 1584 1906 1906 2251 2251 2593 2593 2924 2924 3088 3088
17 2223 1689 2353 2109 2523 2523 2718 2718 2947 2947 3094 3094
19 3416 1782 3416 2157 3405 2521 3439 2905 3518 3299 3563 3497
21 4579 2189 4571 2560 4563 2927 4555 3293 4555 3477
23 5756 2556 5748 2927 5731 3292 5731 3478
9
3
15 1793 1793 1988 1988 2306 2306 2622 2622 2933 2933 3088 3088
17 2636 1891 2624 2256 2650 2631 2732 2732 2941 2941 3094 3094
19 3633 1886 3625 2258 3617 2625 3606 2988 3597 3351 3603 3537
21 4682 2239 4670 2608 4662 2975 4653 3342 4645 3520
23 5813 2585 5801 2954 5789 3321 5781 3503
5
15 1473 1473 1799 1799 2135 2135 2466 2466 2788 2788 2947 2947
17 2070 1617 2161 2016 2308 2308 2508 2508 2794 2794 2952 2952
19 3162 1664 3156 2033 3150 2401 3167 2775 3230 3159 3275 3275
21 4250 2037 4242 2406 4234 2772 4226 3137 4222 3317
23 5402 2394 5394 2763 5377 3127 5377 3313
7
15 1114 1114 1536 1536 1906 1906 2257 2257 2596 2596 2760 2760
17 1340 1244 1663 1663 1963 1963 2262 2262 2602 2602 2766 2766
19 2409 1325 2426 1699 2523 2101 2670 2519 2845 2845 2941 2941
21 3691 1785 3683 2152 3683 2519 3691 2889 3716 3082
23 4908 2173 4900 2541 4892 2907 4884 3087
COOLING CAPACITY CORRECTION FACTORS
