IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 1330 1330 1661 1661 1982 1982 2296 2296 2610 2610 2766 2766
17 1815 1495 1881 1881 2022 2022 2302 2302 2616 2616 2771 2771
19 2822 1508 2817 1876 2811 2240 2814 2608 2873 2873 2907 2907
21 3880 1870 3872 2237 3864 2601 3855 2964 3851 3143
23 5011 2219 4999 2585 4991 2952 4983 3132
5
15 1086 1086 1455 1455 1801 1801 2135 2135 2460 2460 2622 2622
17 1250 1205 1516 1516 1804 1804 2138 2138 2466 2466 2627 2627
19 2228 1245 2234 1614 2302 2002 2429 2407 2596 2596 2689 2689
21 3382 1651 3377 2017 3377 2383 3377 2748 3394 2937
23 4546 2017 4546 2387 4530 2747 4530 2931
7
15 636 636 1142 1142 1550 1550 1915 1915 2262 2262 2432 2432
17 637 637 1148 1148 1552 1552 1920 1920 2268 2268 2435 2435
19 1052 743 1454 1253 1756 1720 2036 2036 2310 2310 2452 2452
21 2630 1335 2636 1703 2715 2094 2839 2501 2913 2704
23 3971 1776 3966 2142 3962 2506 3954 2684
13
3
15 990 990 1329 1329 1656 1656 1974 1974 2288 2288 2443 2443
17 1069 1069 1332 1332 1660 1660 1977 1977 2293 2293 2449 2449
19 1946 1123 1940 1485 1988 1864 2104 2104 2299 2299 2455 2455
21 3020 1497 3015 1862 3009 2222 3003 2582 3017 2768
23 4152 1852 4147 2218 4135 2578 4131 2758
5
15 673 673 1097 1097 1459 1459 1801 1801 2132 2132 2296 2296
17 676 676 1099 1099 1462 1462 1804 1804 2138 2138 2302 2302
19 1058 747 1326 1200 1584 1584 1841 1841 2141 2141 2305 2305
21 2409 1245 2409 1610 2460 1987 2568 2384 2630 2582
23 3625 1637 3617 1999 3609 2358 3609 2540
7
15 321 321 641 641 1168 1168 1561 1561 1923 1923 2096 2096
17 321 321 641 641 1168 1168 1567 1567 1926 1926 2098 2098
19 331 331 644 644 1182 1182 1569 1569 1929 1929 2104 2104
21 1222 777 1567 1254 1855 1708 2121 2121 2245 2245
23 2862 1339 2862 1701 2918 2083 2964 2279
15
3
15 633 633 991 991 1326 1326 1650 1650 1965 1965 2124 2124
17 634 634 993 993 1329 1329 1654 1654 1971 1971 2127 2127
19 925 693 1118 1109 1352 1352 1657 1657 1974 1974 2132 2132
21 2081 1114 2076 1471 2110 1844 2203 2203 2268 2268
23 3232 1482 3230 1844 3218 2200 3215 2379
5
15 257 257 695 695 1104 1104 1462 1462 1801 1801 1968 1968
17 258 258 695 695 1106 1106 1465 1465 1804 1804 1971 1971
19 259 259 701 701 1108 1108 1468 1468 1810 1810 1974 1974
21 1159 754 1408 1193 1651 1624 1895 1895 2019 2019
23 2590 1237 2590 1596 2622 1967 2661 2160
7
15 51 51 321 321 667 667 1185 1185 1572 1572 1753 1753
17 51 51 321 321 667 667 1188 1188 1575 1575 1756 1756
19 51 51 321 321 670 670 1190 1190 1578 1578 1759 1759
21
333 333 690 690 1224 1224 1592 1592 1765 1765
23 1374 795 1691 1253 1963 1695 2093 1912
COOLING CAPACITY - FCLI 42
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 42
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0.82 0.75
Speed V2 360 0.64 0.58
Speed V1 260 0.50 0.44
