IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 1553 1553 1939 1939 2314 2314 2680 2680 3046 3046 3228 3228
17 2118 1671 2195 2103 2360 2360 2687 2687 3053 3053 3235 3235
19 3294 1685 3287 2096 3281 2502 3284 2914 3353 3336 3393 3393
21 4528 2088 4519 2499 4509 2905 4500 3311 4495 3511
23 5849 2479 5834 2888 5825 3297 5815 3499
5
15 1267 1267 1698 1698 2102 2102 2492 2492 2871 2871 3060 3060
17 1459 1346 1769 1769 2106 2106 2495 2495 2878 2878 3066 3066
19 2601 1391 2607 1803 2687 2237 2835 2689 3030 3030 3139 3139
21 3947 1844 3941 2254 3941 2662 3941 3070 3961 3281
23 5306 2253 5306 2666 5287 3069 5287 3274
7
15 742 742 1333 1333 1809 1809 2234 2234 2640 2640 2838 2838
17 744 744 1340 1340 1812 1812 2241 2241 2647 2647 2842 2842
19 1228 830 1696 1400 2050 1921 2376 2376 2696 2696 2862 2862
21 3069 1491 3076 1902 3168 2340 3314 2794 3400 3021
23 4634 1984 4629 2392 4624 2799 4615 2998
13
3
15 1155 1155 1551 1551 1932 1932 2304 2304 2670 2670 2852 2852
17 1247 1247 1554 1554 1937 1937 2307 2307 2677 2677 2858 2858
19 2271 1255 2264 1659 2320 2082 2456 2456 2683 2683 2865 2865
21 3525 1672 3518 2080 3512 2482 3505 2884 3522 3093
23 4845 2068 4840 2478 4826 2880 4821 3081
5
15 785 785 1280 1280 1703 1703 2102 2102 2489 2489 2680 2680
17 788 788 1282 1282 1706 1706 2106 2106 2495 2495 2687 2687
19 1234 835 1548 1341 1848 1833 2149 2149 2498 2498 2690 2690
21 2812 1391 2812 1798 2871 2220 2997 2663 3069 2884
23 4231 1829 4221 2233 4212 2635 4212 2837
7
15 375 375 749 749 1363 1363 1822 1822 2244 2244 2446 2446
17 375 375 749 749 1363 1363 1828 1828 2248 2248 2449 2449
19 386 386 752 752 1380 1380 1832 1832 2251 2251 2456 2456
21 1426 868 1828 1401 2165 1907 2475 2402 2621 2621
23 3340 1496 3340 1900 3406 2327 3459 2546
15
3
15 739 739 1157 1157 1548 1548 1926 1926 2294 2294 2479 2479
17 740 740 1158 1158 1551 1551 1931 1931 2300 2300 2482 2482
19 1079 775 1305 1239 1578 1578 1934 1934 2304 2304 2489 2489
21 2429 1244 2423 1644 2462 2060 2571 2490 2647 2647
23 3773 1656 3769 2060 3756 2458 3753 2658
5
15 300 300 812 812 1289 1289 1706 1706 2102 2102 2297 2297
17 301 301 812 812 1290 1290 1710 1710 2106 2106 2300 2300
19 302 302 818 818 1294 1294 1713 1713 2112 2112 2304 2304
21 1353 843 1644 1332 1927 1815 2211 2211 2357 2357
23 3023 1382 3023 1783 3060 2197 3106 2413
7
15 59 59 375 375 778 778 1383 1383 1835 1835 2046 2046
17 59 59 375 375 778 778 1386 1386 1838 1838 2050 2050
19 59 59 375 375 782 782 1389 1389 1842 1842 2053 2053
21
388 383 805 805 1429 1429 1858 1858 2059 2059
23 1604 888 1974 1400 2291 1893 2442 2136
COOLING CAPACITY - FCLI 64
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 64
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 880 1 1
Speed V3 660 0.79 0.74
Speed V2 500 0.64 0.59
Speed V1 380 0.53 0.49
