23
IFCLITY1106 - 5773010_01
COOLING CAPACITY - FCLI 82
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 4820 3538 4798 4026 4820 4516 4970 4970 5438 5438 5675 5675
17 6219 3520 6206 4017 6194 4507 6181 4995 6162 5479 6169 5722
19 7731 3492 7712 3990 7693 4483 7675 4974 7656 5456 7643 5699
21 9331 3952 9306 4447 9281 4936 9256 5425 9249 5669
23 11043 4397 11030 4898 10993 5384 10980 5629
5
15 4158 3216 4253 3739 4433 4267 4742 4742 5219 5219 5456 5456
17 5638 3245 5625 3739 5606 4227 5631 4727 5694 5225 5756 5479
19 7168 3229 7156 3729 7143 4223 7131 4716 7119 5200 7094 5437
21 8793 3703 8768 4197 8756 4691 8737 5181 8731 5425
23 10530 4162 10505 4655 10480 5146 10468 5390
7
15 3333 2801 3643 3389 3982 3946 4442 4442 4940 4940 5189 5189
17 4794 2860 4785 3353 4863 3869 5017 4407 5224 4945 5361 5217
19 6494 2926 6481 3423 6469 3915 6444 4400 6456 4893 6469 5143
21 8168 3424 8143 3916 8131 4408 8118 4899 8106 5139
23 9930 3896 9918 4393 9893 4883 9880 5126
7
3
15 3742 3021 3793 3520 3999 3999 4476 4476 4949 4949 5181 5181
17 5151 3021 5138 3513 5121 4000 5116 4487 5206 4991 5275 5229
19 6656 2999 6644 3496 6631 3990 6606 4472 6600 4958 6581 5195
21 8256 3465 8231 3956 6606 4472 8193 4933 8187 5177
23 9968 3916 9955 4413 9930 4902 9918 5145
5
15 3089 2692 3359 3248 3750 3750 4244 4244 4730 4730 4966 4966
17 4476 2719 4459 3207 4519 3715 4648 4238 4846 4756 5009 5009
19 6037 2727 6025 3223 6019 3716
6000 4200
5994 4686 6006 4936
21 7668 3209 7656 3705 7643 4195 7618 4678 7612 4920
23 9405 3673 9393 4167 9368 4655 9356 4898
7
15 2405 2291 2895 2895 3419 3419 3939 3939 4442 4442 4691 4691
17 3376 2245 3574 2803 3832 3370 4128 3932 4476 4472 4700 4700
19 5189 2369 5189 2867 5172 3351 5224 3861 5344 4385 5413 4648
21 6956 2910 6944 3402 6931 3890 6919 4377 6919 4621
23 8743 3397 8731 3890 8706 4375 8706 4623
9
3
15 2723 2525 3020 3020 3503 3503 3982 3982 4455 4455 4691 4691
17 4004 2513 3986 2999 4025 3497 4150 4005 4468 4468 4700 4700
19 5519 2507 5506 3001 5494 3489 5477 3971 5464 4454 5473 4701
21 7112 2976 7094 3466 7081 3955 7069 4442 7056 4679
23 8831 3435 8812 3926 8793 4414 8781 4655
5
15 2238 2206 2732 2732 3243 3243 3746 3746 4236 4236 4476 4476
17 3144 2149 3282 2679 3505 3225 3810 3767 4244 4244 4485 4485
19 4803 2211 4794 2703 4785 3191 4811 3688 4906 4198 4974 4458
21 6456 2707 6444 3198 6431 3684 6419 4169 6412 4408
23 8206 3181 8193 3672 8168 4156 8168 4403
7
15 1692 1692 2332 2332 2895 2895 3428 3428 3943 3943 4193 4193
17 2036 1654 2526 2292 2981 2896 3437 3437 3952 3952 4201 4201
19 3660 1761 3686 2258 3832 2792 4055 3348 4321 3902 4468 4183
21 5606 2373 5594 2860 5594 3348 5606 3840 5644 4096
23 7456 2889 7443 3377 7431 3864 7418 4103
COOLING CAPACITY CORRECTION FACTORS
FCLI 82
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 1100 1 1
Speed V3 830 0.80 0.79
Speed V2 680 0.68 0.66
Speed V1 460 0.47 0.45
