24
IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 2021 2021 2524 2524 3011 3011 3488 3488 3965 3965 4201 4201
17 2757 1988 2857 2502 3071 3023 3497 3497 3973 3973 4210 4210
19 4287 2005 4279 2494 4270 2977 4274 3467 4364 3969 4416 4219
21 5894 2485 5881 2973 5869 3457 5856 3939 5850 4177
23 7612 2950 7593 3436 7581 3923 7568 4163
5
15 1649 1649 2210 2210 2736 2736 3243 3243 3737 3737 3982 3982
17 1899 1601 2302 2194 2741 2741 3247 3247 3746 3746 3991 3991
19 3385 1655 3394 2145 3497 2661 3690 3199 3943 3740 4085 4005
21 5138 2194 5129 2681 5129 3167 5129 3652 5155 3903
23 6906 2681 6906 3172 6881 3652 6881 3895
7
15 966 966 1735 1735 2354 2354 2908 2908 3437 3437 3694 3694
17 968 968 1744 1744 2358 2358 2917 2917 3445 3445 3699 3699
19 1598 988 2208 1665 2668 2286 3093 2883 3510 3452 3724 3724
21 3995 1774 4004 2263 4124 2784 4313 3324 4425 3594
23 6031 2361 6025 2846 6019 3331 6006 3567
13
3
15 1503 1503 2019 2019 2515 2515 2998 2998 3475 3475 3711 3711
17 1624 1487 2023 2023 2521 2521 3003 3003 3484 3484 3720 3720
19 2955 1493 2947 1973 3020 2477 3196 2995 3492 3492 3729 3729
21 4588 1990 4579 2474 4571 2953 4562 3432 4584 3680
23 6306 2461 6300 2948 6281 3427 6275 3666
5
15 1022 1022 1667 1667 2216 2216 2736 2736 3239 3239 3488 3488
17 1026 1026 1669 1669 2221 2221 2741 2741 3247 3247 3497 3497
19 1606 993 2015 1595 2405 2181 2796 2745 3252 3252 3501 3501
21 3660 1655 3660 2139 3737 2641 3900 3169 3995 3432
23 5506 2176 5494 2657 5481 3135 5481 3376
7
15 488 488 974 974 1774 1774 2371 2371 2921 2921 3183 3183
17 488 488 974 974 1774 1774 2380 2380 2925 2925 3187 3187
19 503 464 979 979 1795 1782 2384 2384 2930 2930 3196 3196
21 1856 1033 2380 1667 2818 2270 3222 2858 3411 3143
23 4347 1780 4347 2261 4433 2769 4502 3029
15
3
15 961 961 1505 1505 2015 2015 2506 2506 2985 2985 3226 3226
17 963 963 1508 1508 2019 2019 2513 2513 2994 2994 3230 3230
19 1405 922 1699 1474 2053 2025 2517 2517 2998 2998 3239 3239
21 3162 1481 3153 1955 3205 2451 3346 2963 3445 3219
23 4910 1970 4906 2451 4889 2925 4884 3162
5
15 390 390 1056 1056 1677 1677 2221 2221 2736 2736 2990 2990
17 391 391 1056 1056 1679 1679 2225 2225 2741 2741 2994 2994
19 393 391 1065 1065 1684 1684 2229 2229 2749 2749 2998 2998
21 1761 1003 2139 1585 2509 2159 2878 2721 3067 2997
23 3935 1644 3935 2121 3982 2614 4042 2871
7
15 77 77 488 488 1013 1013 1800 1800 2388 2388 2663 2663
17 77 77 488 488 1013 1013 1804 1804 2393 2393 2668 2668
19 77 77 488 488 1017 1017 1808 1808 2397 2397 2672 2672
21
505 456 1048 1029 1860 1794 2418 2403 2680 2680
23 2088 1057 2569 1666 2981 2253 3179 2541
COOLING CAPACITY - FCLI 82
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 82
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 1100 1 1
Speed V3 830 0.80 0.79
Speed V2 680 0.68 0.66
Speed V1 460 0.47 0.45
