26
IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 3705 3705 4627 4627 5521 5521 6395 6395 7269 7269 7702 7702
17 5055 4008 5237 5045 5631 5631 6411 6411 7285 7285 7718 7718
19 7860 4043 7844 5029 7828 6003 7836 6991 8001 8001 8096 8096
21 10805 5011 10782 5996 10759 6971 10737 7943 10725 8423
23 13956 5949 13921 6930 13898 7912 13875 8395
5
15 3024 3024 4052 4052 5016 5016 5946 5946 6852 6852 7300 7300
17 3481 3230 4221 4221 5024 5024 5954 5954 6867 6867 7316 7316
19 6206 3338 6221 4326 6411 5367 6765 6452 7230 7230 7490 7490
21 9419 4425 9403 5407 9403 6387 9403 7365 9451 7872
23 12661 5406 12661 6398 12615 7364 12615 7856
7
15 1770 1770 3181 3181 4316 4316 5332 5332 6300 6300 6773 6773
17 1774 1774 3197 3197 4323 4323 5347 5347 6316 6316 6781 6781
19 2929 1992 4048 3359 4890 4609 5670 5670 6434 6434 6828 6828
21 7324 3578 7340 4564 7560 5614 7907 6704 8112 7248
23 11057 4761 11046 5740 11034 6717 11011 7193
13
3
15 2756 2756 3701 3701 4611 4611 5497 5497 6371 6371 6804 6804
17 2977 2977 3709 3709 4623 4623 5505 5505 6387 6387 6820 6820
19 5418 3011 5402 3980 5536 4995 5859 5859 6403 6403 6836 6836
21 8411 4013 8395 4990 8379 5955 8364 6921 8403 7421
23 11561 4963 11550 5945 11516 6911 11504 7393
5
15 1873 1873 3055 3055 4064 4064 5016 5016 5938 5938 6395 6395
17 1881 1881 3059 3059 4071 4071 5024 5024 5954 5954 6411 6411
19 2945 2003 3693 3218 4410 4398 5127 5127 5962 5962 6418 6418
21 6710 3337 6710 4314 6852 5326 7151 6390 7324 6921
23 10095 4388 10072 5358 10049 6321 10049 6807
7
15 894 894 1786 1786 3252 3252 4347 4347 5355 5355 5836 5836
17 894 894 1786 1786 3252 3252 4363 4363 5363 5363 5843 5843
19 922 922 1794 1794 3292 3292 4371 4371 5371 5371 5859 5859
21 3402 2083 4363 3362 5166 4577 5906 5764 6253 6253
23 7970 3590 7970 4559 8127 5583 8253 6108
15
3
15 1762 1762 2760 2760 3693 3693 4595 4595 5473 5473 5914 5914
17 1766 1766 2764 2764 3701 3701 4607 4607 5489 5489 5922 5922
19 2575 1858 3114 2973 3764 3764 4615 4615 5497 5497 5938 5938
21 5796 2986 5780 3944 5875 4942 6135 5975 6316 6316
23 9002 3973 8994 4942 8962 5898 8954 6377
5
15 716 716 1937 1937 3075 3075 4071 4071 5016 5016 5481 5481
17 717 717 1937 1937 3079 3079 4079 4079 5024 5024 5489 5489
19 721 721 1953 1953 3087 3087 4087 4087 5040 5040 5497 5497
21 3229 2022 3922 3196 4599 4354 5276 5276 5623 5623
23 7214 3316 7214 4278 7300 5272 7411 5789
7
15 142 142 894 894 1857 1857 3300 3300 4379 4379 4883 4883
17 142 142 894 894 1857 1857 3307 3307 4386 4386 4890 4890
19 142 142 894 894 1865 1865 3315 3315 4394 4394 4898 4898
21
927 920 1921 1921 3410 3410 4434 4434 4914 4914
23 3827 2131 4709 3359 5465 4543 5828 5125
COOLING CAPACITY - FCLI 122
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 122
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 1750 1 1
Speed V3 1350 0.81 0.81
Speed V2 1100 0.68 0.68
Speed V1 750 0.49 0.48
