COOLING CAPACITY - FCLI 124
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 7069 5703 7038 6489 7069 7069 7290 7290 7976 7976 8323 8323
17 9121 5674 9102 6475 9084 7265 9066 8051 9038 8831 9047 9047
19 11339 5628 11311 6431 11284 7227 11256 8017 11229 8795 11210 9185
21 13685 6370 13648 7168 13611 7957 13575 8744 13566 9138
23 16196 7088 16178 7895 16123 8678 16104 9073
5
15 6099 5184 6237 6027 6502 6502 6956 6956 7655 7655 8002 8002
17 8268 5230 8250 6027 8223 6814 8259 7619 8351 8351 8443 8443
19 10514 5205 10495 6010 10477 6807 10459 7601 10440 8382 10404 8764
21 12897 5969 12860 6765 12842 7562 12814 8351 12805 8745
23 15444 6709 15408 7503 15371 8294 15353 8687
7
15 4889 4515 5343 5343 5840 5840 6515 6515 7245 7245 7611 7611
17 7031 4610 7019 5405 7132 6236 7359 7104 7661 7661 7863 7863
19 9524 4716 9506 5517 9487 6311 9451 7092 9469 7887 9487 8290
21 11980 5519 11943 6311 11925 7105 11907 7897 11888 8283
23 14565 6280 14546 7081 14510 7870 14491 8262
7
3
15 5488 4870 5563 5563 5866 5866 6565 6565 7258 7258 7598 7598
17 7554 4869 7535 5663 7510 6448 7504 7233 7636 7636 7737 7737
19 9762 4834 9744 5636 9726 6431 9689 7208 9680 7992 9652 8373
21 12108 5585 12072 6377 9689 7208 12017 7952 12008 8344
23 14620 6312 14601 7113 14565 7902 14546 8294
5
15 4530 4339 4927 4927 5500 5500 6225 6225 6937 6937 7283 7283
17 6565 4383 6540 5169 6628 5989 6817 6817 7107 7107 7346 7346
19 8855 4396 8837 5195 8827 5989
8800 6770
8791 7553 8809 7957
21 11247 5172 11229 5972 11210 6762 11174 7541 11164 7931
23 13795 5920 13776 6717 13740 7504 13721 7895
7
15 3528 3528 4246 4246 5015 5015 5777 5777 6515 6515 6880 6880
17 4952 3618 5242 4518 5620 5432 6055 6055 6565 6565 6893 6893
19 7611 3819 7611 4621 7586 5402 7661 6223 7838 7068 7939 7493
21 10202 4690 10184 5484 10166 6271 10147 7055 10147 7449
23 12823 5476 12805 6270 12768 7053 12768 7451
9
3
15 3994 3994 4429 4429 5138 5138 5840 5840 6533 6533 6880 6880
17 5872 4051 5847 4834 5903 5637 6086 6086 6552 6552 6893 6893
19 8094 4042 8076 4837 8058 5623 8033 6401 8014 7179 8027 7578
21 10431 4797 10404 5587 10385 6375 10367 7160 10349 7542
23 12952 5537 12924 6328 12897 7115 12878 7504
5
15 3282 3282 4007 4007 4757 4757 5494 5494 6212 6212 6565 6565
17 4612 3463 4813 4319 5141 5141 5588 5588 6225 6225 6578 6578
19 7044 3565 7031 4356 7019 5143 7056 5945 7195 6767 7296 7186
21 9469 4364 9451 5155 9432 5938 9414 6720 9405 7106
23 12035 5128 12017 5919 11980 6700 11980 7097
7
15 2482 2482 3421 3421 4246 4246 5028 5028 5784 5784 6149 6149
17 2986 2666 3704 3695 4372 4372 5040 5040 5796 5796 6162 6162
19 5368 2838 5406 3640 5620 4500 5948 5396 6338 6290 6552 6552
21 8223 3825 8204 4610 8204 5397 8223 6190 8278 6603
23 10935 4656 10917 5443 10899 6228 10880 6613
COOLING CAPACITY CORRECTION FACTORS
FCLI 124
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 1750 1 1
Speed V3 1350 0.83 0.82
Speed V2 1100 0.71 0.69
Speed V1 750 0.52 0.50
