28
IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 2964 2964 3701 3701 4416 4416 5116 5116 5815 5815 6162 6162
17 4044 3204 4190 4033 4505 4505 5128 5128 5828 5828 6174 6174
19 6288 3231 6275 4020 6263 4798 6269 5588 6401 6398 6477 6477
21 8644 4005 8626 4793 8608 5572 8589 6349 8580 6733
23 11164 4755 11137 5539 11119 6324 11100 6710
5
15 2419 2419 3241 3241 4013 4013 4757 4757 5481 5481 5840 5840
17 2785 2581 3377 3377 4019 4019 4763 4763 5494 5494 5853 5853
19 4965 2668 4977 3458 5128 4290 5412 5157 5784 5784 5992 5992
21 7535 3537 7523 4322 7523 5105 7523 5887 7560 6292
23 10129 4321 10129 5114 10092 5886 10092 6279
7
15 1416 1416 2545 2545 3452 3452 4265 4265 5040 5040 5418 5418
17 1419 1419 2558 2558 3459 3459 4278 4278 5053 5053 5425 5425
19 2344 1592 3238 2685 3912 3684 4536 4536 5147 5147 5462 5462
21 5859 2860 5872 3648 6048 4487 6326 5358 6489 5794
23 8846 3806 8837 4588 8827 5369 8809 5749
13
3
15 2205 2205 2961 2961 3689 3689 4398 4398 5097 5097 5443 5443
17 2381 2381 2967 2967 3698 3698 4404 4404 5110 5110 5456 5456
19 4335 2407 4322 3181 4429 3992 4687 4687 5122 5122 5469 5469
21 6729 3207 6716 3989 6704 4760 6691 5532 6722 5931
23 9249 3967 9240 4752 9212 5524 9203 5909
5
15 1499 1499 2444 2444 3251 3251 4013 4013 4750 4750 5116 5116
17 1505 1505 2447 2447 3257 3257 4019 4019 4763 4763 5128 5128
19 2356 1601 2955 2572 3528 3516 4101 4101 4769 4769 5135 5135
21 5368 2668 5368 3448 5481 4257 5721 5108 5859 5532
23 8076 3507 8058 4282 8039 5053 8039 5441
7
15 715 715 1429 1429 2602 2602 3478 3478 4284 4284 4668 4668
17 715 715 1429 1429 2602 2602 3490 3490 4290 4290 4675 4675
19 738 738 1435 1435 2633 2633 3497 3497 4297 4297 4687 4687
21 2722 1665 3490 2687 4133 3658 4725 4607 5002 5002
23 6376 2869 6376 3644 6502 4463 6603 4882
15
3
15 1410 1410 2208 2208 2955 2955 3676 3676 4379 4379 4731 4731
17 1413 1413 2211 2211 2961 2961 3686 3686 4391 4391 4738 4738
19 2060 1485 2492 2376 3011 3011 3692 3692 4398 4398 4750 4750
21 4637 2387 4624 3152 4700 3950 4908 4775 5053 5053
23 7201 3176 7195 3950 7170 4714 7164 5097
5
15 572 572 1549 1549 2460 2460 3257 3257 4013 4013 4385 4385
17 574 574 1549 1549 2463 2463 3263 3263 4019 4019 4391 4391
19 577 577 1562 1562 2470 2470 3270 3270 4032 4032 4398 4398
21 2583 1616 3137 2555 3679 3480 4221 4221 4498 4498
23 5771 2651 5771 3420 5840 4214 5929 4627
7
15 113 113 715 715 1486 1486 2640 2640 3503 3503 3906 3906
17 113 113 715 715 1486 1486 2646 2646 3509 3509 3912 3912
19 113 113 715 715 1492 1492 2652 2652 3515 3515 3919 3919
21
741 735 1537 1537 2728 2728 3547 3547 3931 3931
23 3062 1704 3767 2685 4372 3631 4662 4096
COOLING CAPACITY - FCLI 124
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 124
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 1750 1 1
Speed V3 1350 0.83 0.82
Speed V2 1100 0.71 0.69
Speed V1 750 0.52 0.50
