33
English
The blades on the air discharge are arranged to direct the air in
two directions:
– vertical blades, to be adjusted manually
– motorised horizontal blades for versions with microprocessor
controller, to be adjusted only by means of the TLW2 remote
control or the PFW2 wired control panel
– horizontal blades for versions without microprocessor control-
ler to be adjusted manually.
– turn the vertical blades as indicated in the diagram
– both in heating or cooling mode it is advisable for the air flow
not to hit people directly.
cause a malfunction.
When the unit is off the blades close and cover the air flow outlet.
Under particular external conditions condensate might occur on
the surface of the blades (during cooling and dehumidification)
and drip onto the surfaces below.
DIRECTION OF THE AIR FLOW
LOUVER
TLW2 PFW2
coil unit.
The direction of air flow as shown in the
diagram
PFW2
TLW2
