AERMEC FW160R - Fault Identification and Alarms; Troubleshooting Common Problems; Alarm Codes and Display

33
FWR 1406 - 5388000_02
For anomalies not detailed immediately call the Service Assistance.
PROBLEM PROBABLE CAUSA SOLUTION
LOW SUPPLY AIR FLOW
WRONG FAN SPEED SETTING ON THE WIRED PANEL SELECT THE FAN SPEED ON THE WIRED PANEL
DIRTY FILTER CLEAN THE FILTER
AIR FLOW OBSTRUCTION
(INTAKE AND/OR OUTLET)
REMOVE THE OBSTRUCTION
DOES NOT HEAT WRONG PANEL SETTING SET CONTROL PANEL
ELECTRIC HEATER DOES NOT OPERATE
LACK OF CURRENT CHECK THE ELECTRICAL POWER SUPPLY
MANUAL RESET SAFETY THERMOSTAT HAS
OPERATED
CALL THE SERVICE ASSISTANCE
INTERMITTENT OPERATION
ELECTRIC HEATER INCORRECTLY INSTALLED
CHECK THE CORRECT POSITION OF THE
THERMOSTATS
FILTER DIRTY CLEAN THE FILTER
AIR FLOW OBSTRUCTION
(INTAKE AND/OR OUTLET)
REMOVE THE OBSTRUCTION
AUTOMATIC RESET SAFETY THERMOSTAT HAS
OPERATED
IF THE PROBLEM PERSISTS CONTACT THE SERVICE
ASSISTANCE
DOES NOT COOL WRONG CONTROL PANEL SETTING SET CONTROL PANEL
THE FAN DOES NOT ROTATE LACK OF CURRENT CHECK THE ELECTRICAL POWER SUPPLY
FAULT IDENTIFICATION
Led display Alarms
❍❒ ❍ ❍ ❍ ❍ Ambient sensor
❍ ❍❒ ❍ ❍ ❍ Defrost sensor
❍❒ ❍❒ ❍ ❍ ❍ Water sensor
❍❒ ❍ ❍❒ ❍ ❍ Coil overheat
❍ ❍❒ ❍❒ ❍ ❍ Anti-frost
❍❒ ❍❒ ❍❒ ❍ ❍ External contact
❍ = Yellow LED on
❒ = Red LED on
ALARM CODES TABLE
The air conditioner features a self-protection program that, in the event of anomalous situations, automatically shuts down unit opera-
tion and places it in pre-alarm status. In such a case, there are two resolution possibilities:
a) If the pre-alarm persists for a time greater than the maximum programmed for the fault type, the unit goes to Alarm status.
b) If the fault is no longer present, the pre-alarm status ceases and the unit can resume operation, in accordance with the safety
time required by the compressor.
ALARM DISPLAY
In the event that the air conditioner goes to Alarm status, the fault type will be automatically displayed by a special sequence of yellow
and red light flashes on the wall receiver LED.
The following alarm codes are possible:
❍ Yellow LED: flashes cyclically 5 times, then goes out for 5 seconds.
❒ Red LED: lights up when the yellow LED goes out, thus indicating a specific code.
ALARMS
