18 21.05 – 5167557_02
Model Hydronic kit
Empty weight
(lbs)
Centre of mass A B C D E F
Xg (in) Yg (in) % % % % % %
0150
00 820 13.7 38.5 24 20 30 26 - -
P1-P3 869 13.8 36.7 25 22 28 25 - -
01-03 979 13.9 36.8 25 22 28 25 - -
0300
00 1,729 21.9 46.8 31 32 18 19 - -
P2-P4 1,892 22.3 49.9 30 31 19 20 - -
P1-P3 1,844 22.3 48.8 30 32 18 20 - -
02-04 2,146 21.9 51.9 29 30 20 20 - -
01-03 2,097 21.9 51.0 30 30 20 20 - -
0330
00 1,846 21.9 55.8 28 29 21 22 - -
P2-P4 2,009 21.9 59.1 27 28 22 23 - -
P1-P3 1,961 21.9 58.1 28 28 22 22 - -
02-04 2,296 21.9 62.2 26 27 23 24 - -
01-03 2,247 21.9 61.1 26 27 23 24 - -
0350
00 1,938 21.9 57.0 28 29 21 22 - -
P2-P4 2,101 21.9 60.0 27 27 23 23 - -
P1-P3 2,052 21.9 59.1 27 28 22 23 - -
02-04 2,387 21.9 62.9 26 26 24 24 - -
01-03 2,339 21.9 61.9 26 27 23 24 - -
0550
00 1,955 21.9 57.1 28 29 21 22 - -
P2-P4 2,118 21.9 60.1 27 27 23 23 - -
P1-P3 2,070 21.9 59.2 27 28 22 23 - -
02-04 2,405 21.9 62.9 26 26 24 24 - -
01-03 2,356 21.9 61.9 26 27 23 24 - -
0600
00 2,544 21.7 66.6 12 12 30 30 8 8
P2-P4 2,711 21.7 69.0 11 11 31 31 8 8
P1-P3 2,661 21.7 68.4 11 11 31 31 8 8
02-04 2,998 21.7 70.8 9 9 33 34 8 8
01-03 2,947 21.7 70.0 9 9 33 33 8 8
0650
00 2,544 21.7 66.6 12 12 30 30 8 8
P2-P4 2,711 21.7 69.0 11 11 31 31 8 8
P1-P3 2,661 21.7 68.4 11 11 31 31 8 8
02-04 2,998 21.7 70.8 9 9 33 34 8 8
01-03 2,947 21.7 70.0 9 9 33 33 8 8
0700
00 2,596 21.7 66.3 12 12 30 31 8 8
P2-P4 2,764 21.7 68.6 11 11 31 32 8 8
P1-P3 2,713 21.7 68.1 11 11 31 31 8 8
02-04 3,050 21.7 70.4 9 9 34
34 8 8
01-03 3,000 21.7 69.6 9 9 33 34 7 7
