AERMEC NRK 0650 A - Page 19

21.05 – 5167557_02 19
Model Hydronic kit
Operation
weight (lbs)
Centre of mass A B C D E F
VT
Xg (in) Yg (in) % % % % % %
0150
00 833 13.7 38.5 24 20 30 26 - - VT 15
P1-P3 882 13.8 36.7 25 22 28 25 - - VT 15
01-03 1,212 13.9 36.8 25 22 28 25 - - VT 15
0300
00 1,742 21.9 46.7 31 32 18 18 - - VT17
P2-P4 1,927 22.4 50.0 29 31 19 20 - - VT17
P1-P3 1,878 22.4 48.9 30 32 18 20 - - VT17
02-04 2,842 21.8 55.5 28 29 22 22 - - VT13
01-03 2,793 21.8 54.9 28 29 21 22 - - VT13
0330
00 1,862 21.9 55.8 28 29 21 22 - - VT11
P2-P4 2,047 21.9 59.4 27 28 22 23 - - VT11
P1-P3 1,999 21.9 58.5 27 28 22 23 - - VT11
02-04 3,436 21.8 68.6 24 24 26 26 - - VT11
01-03 3,388 21.8 68.0 24 24 26 26 - - VT11
0350
00 1,958 21.9 56.9 28 29 21 22 - - VT11
P2-P4 2,143 21.9 60.3 27 27 23 23 - - VT11
P1-P3 2,095 21.9 59.4 27 28 22 23 - - VT11
02-04 3,532 21.8 68.9 24 24 26 26 - - VT11
01-03 3,484 21.8 68.3 24 24 26 26 - - VT11
0550
00 1,976 21.9 57.1 28 29 21 22 - - VT11
P2-P4 2,161 21.9 60.4 27 27 23 23 - - VT11
P1-P3 2,112 21.9 59.5 27 28 22 23 - - VT11
02-04 3,550 21.8 68.9 24 24 26 26 - - VT11
01-03 3,501 21.8 68.3 24 24 26 26 - - VT11
0600
00 2,572 21.7 66.5 12 12 31 31 8 8 VT22
P2-P4 2,761 21.7 69.2 10 10 31 32 8 8 VT22
P1-P3 2,711 21.7 68.7 11 11 31 31 8 8 VT22
02-04 4,150 21.7 75.2 4 4 39 39 7 7 VT22
01-03 4,099 21.7 74.7 4 4 39 39 7 7 VT22
0650
00 2,572 21.7 66.5 12 12 31 31 8 8 VT22
P2-P4 2,761 21.7 69.2 10 10 31 32 8 8 VT22
P1-P3 2,711 21.7 68.7 11 11 31 31 8 8 VT22
02-04 4,150 21.7 75.2 4 4 39 39 7 7 VT22
01-03 4,099 21.7 74.7 4 4 39 39 7 7 VT22
0700
00 2,626
21.7 66.2 12 12 31 31 8 8 VT22
P2-P4 2,815 21.7 68.9 10 10 32 32 8 8 VT22
P1-P3 2,765 21.7 68.4 11 11 31 32 8 8 VT22
02-04 4,204 21.7 74.9 4 4 39 39 7 7 VT22
01-03 4,154 21.7 74.4 4 4 39 39 7 7 VT22
