AERMEC NRP 0750 - Page 31

31Aermec cod. 5806715_00 12.01
NRP 0200-0750
EN
WEIGHT OF UNITS WHEN EMPTY
HYDRONIC
KIT
BARYCENTRE
(mm)
WEIGHT DISTRIBUTION
ON SUPPORTS (%)
VT KIT
WEIGHT
UNIT
WEIGHT
PALLET
Gx Gy A B C D
NRP0200 01-03 918 31 556 1092 22% 24% 25% 28%
NRP0200 02-04 933 31
556 1109 22% 24% 26% 28%
NRP0200 1 pump 813 31
556 1042 23% 26% 24% 27%
NRP0200 2 pumps 828 31
556 1062 23% 25% 25% 27%
NRP0200 3 pumps 843 31
556 1081 22% 25% 25% 28%
NRP0200 4 pumps 858 31
556 1100 22% 24% 26% 28%
NRP0240 01-03 920 31
556 1090 22% 25% 25% 28%
NRP0240 02-04 935 31
556 1107 22% 24% 26% 28%
NRP0240 1 pump 815 31
557 1040 23% 26% 24% 27%
NRP0240 2 pumps 830 31
556 1060 23% 25% 25% 27%
NRP0240 3 pumps 845 31
556 1079 23% 25% 25% 28%
NRP0240 4 pumps 860 31
556 1098 22% 24% 25% 28%
NRP0280 01-03 922 31
556 1089 22% 25% 25% 28% 13
NRP0280 02-04 937 31
556 1105 22% 24% 26% 28% 13
NRP0280 1 pump 817 31
557 1038 23% 26% 24% 27% 17
NRP0280 2 pumps 832 31
556 1058 23% 25% 25% 27% 17
NRP0280 3 pumps 847 31
556 1077 23% 25% 25% 28% 17
NRP0280 4 pumps 862 31
556 1096 22% 24% 25% 28% 17
WEIGHT OF UNITS WHEN RUNNING
HYDRONIC
KIT
BARYCENTRE
(mm)
WEIGHT DISTRIBUTION
ON SUPPORTS (%)
VT KIT
WEIGHT
UNIT
WEIGHT
PALLET
Gx Gy A B C D
NRP0200 01-03 1248
554 1204 20% 22% 28% 31%
NRP0200 02-04 1263
554 1216 19% 21% 28% 31%
NRP0200 1 pump 853
556 1056 23% 25% 24% 27%
NRP0200 2 pumps 868
556 1075 23% 25% 25% 28%
NRP0200 3 pumps 883
556 1093 22% 24% 25% 28%
NRP0200 4 pumps 898
556 1111 22% 24% 26% 28%
NRP0240 01-03 1250
554 1203 20% 22% 28% 31%
NRP0240 02-04 1265
554 1214 19% 21% 28% 31%
NRP0240 1 pump 855
556 1054 23% 25% 24% 27%
NRP0240 2 pumps 870
556 1073 23% 25% 25% 27%
NRP0240 3 pumps 885
556 1091 22% 25% 25% 28%
NRP0240 4 pumps 900
556 1109 22% 24% 26% 28%
NRP0280 01-03 1273
554 1206 20% 22% 28% 31% 13
NRP0280 02-04 1288
554 1217 19% 21% 28% 31% 13
NRP0280 1 pump 858
556 1052 23% 26% 24% 27% 17
NRP0280 2 pumps 873
556 1070 23% 25% 25% 27% 17
NRP0280 3 pumps 888
556 1089 22% 25% 25% 28% 17
NRP0280 4 pumps 903
556 1106 22% 24% 26% 28% 17
