AERMEC NYB - Dimensions; Minimum Technical Spaces

20.05 – 4138421_03 11
DIMENSIONS
MINIMUM TECHNICAL SPACES
NYB
Vers A1 B1 B2 C1 C2
in in in in in
0500 A 118 79 59 - -
47 in
ELECTRICAL
BOX
C2
B2
C1
B1
A1
96.5 in
86.7 in
6.6 in
46.9 in
9.9 in11.9 in
5.0 in
