Control panels
AER503IR: Flush-mounting thermostat with backlit display, capacitive
keypad and infrared receiver, for controlling both brushless fan coils
and those with an asynchronous motor. In 2-pipe systems, the thermo-
stat can control standard fan coils or those equipped with an electric
heater, with air purifying devices (Cold Plasma and germicidal lamp),
with radiant plate or with FCZ-D twin delivery (Dualjet). In addition, it
can control systems with radiant panels or mixed (fan coil and radiant
oor) systems. Being equipped with an infrared receiver, it can, in turn,
be controlled by the VMF-IR remote control.
PRO503: Wall box for AER503IR and VMF-E4 thermostats.
SA5: air probe kit (L = 15 m) with probe-locking cable grommet.
SIT3: Thermostat Interface Card allowing the creation of a network of
fan coils (max. 10) commanded by a central control panel (selector or
thermostat). Commands the 3 fan speeds and must be installed on each
fan coil within the network; receives the commands from the selector
or the SIT5 card.
SIT5: Thermostat Interface Card allowing the creation of a network of
fan coils (max. 10) commanded by a central control panel. Commands
the 3 fan speeds and up to 2 valves (four pipe systems); sends the ther-
mostat's commands to the fan coil network.
SW3: Water probe (L = 2.5 m) for controlling the minimum and maxi-
mum and to allow automatic seasonal switching for electronic thermo-
stats tted with water side changeover.
SW5: water probe kit (L = 15m) with probe-holder connection point,
xing clip and probe-holder from heat exchanger.
TX: Wall-mounting thermostat for controlling either brushless fan coils
or those with asynchronous motors. In 2-pipe systems, the thermostat
can control standard fan coils or those equipped with an electric heater,
with air purifying devices, radiant plate or FCZ-D twin delivery (Dualjet).
WMT05: Electronic thermostat with thermostated ventilation.
WMT06: Electronic thermostat with continuous ventilation.
WMT10: Electronic thermostat, white, with thermostated or continu-
ous ventilation.
VMF system
VMF-E0X: Thermostat to be secured to the side of the fan coil, tted as
standard with an air probe and a water probe.
VMF-E19: Thermostat to be secured to the side of the fan coil, tted as
standard with an air probe and a water probe.
VMF-E4DX: Wall-mounted user interface. Grey front panel PANTONE
425C (METAL).
VMF-E4X: Wall-mounted user interface. Light grey front panel PAN-
TONE COOL GRAY 1C.
VMF-IO: Manage the unit exclusively from a centralized VMF control
panel without area control panel.
VMF-LON: Expansion allowing the thermostat to interface with BMS
systems that use the LON protocol.
VMF-MOD: Expansion board for the management of modulating
valves.
VMF-SIT3: Interface card that permits connecting the VMF-E19 ther-
mostats to a fan coil with a high power motor.
VMF-SW1: Extra water probe to be used for 4-pipe systems.
Water valves
VJP: Control and balancing combination valve for 2 and 4 pipe systems
to install outside the unit, supplied without ttings and hydraulic com-
ponents. The valve, which can guarantee a constant water ow rate in
the terminal, within its operating range.
VCT: These are 3-way ball valves made of bronze, with female/female
connections Ø 1/2". That can be servo-activated via servo commands.
The valves do not have ttings and pipes for water connections, which
are the installer's responsibility.
VCT: These are 3-way ball valves made of bronze, with female/female
connections Ø 1/2". That can be servo-activated via servo commands.
The valves do not have ttings and pipes for water connections, which
are the installer's responsibility.
VCTK: The VCT series valves can be combined with the actuators On-
O 230V. The actuator must be selected according to the type of sys-
tem/adjustment provided.
VCTKM: The VCT series valves can be combined with the actuators 24V
modulating. The actuator must be selected according to the type of sys-
tem/adjustment provided.
VCF45C - 47C - for main coil: Motorized 3-way valve kit for main coil.
The kit consists of a 4-way 4-way valve with its insulating shell, the ac-
tuator and the relative hydraulic ttings, it is suitable for installation on
both fan coil units with hydraulic connections on the right and left.
VCF45H - 47H - for heating only coil: Motorized 3-way valve kit for
hot only coil. The kit consists of a 3-way 4-way valve, the actuator and
its hydraulic ttings, it is suitable for installation on both fan coil units
with hydraulic connections on the right and left.
VCF25C - for main coil: 2-way motorized valve kit for main coil. The kit
consists of a valve with its insulating shell, the actuator and the relative
hydraulic ttings, it is suitable for installation on both fan coil units with
hydraulic connections on the right and left.
VCF25H - for heating only coil: 2-way motorized valve kit for hot only
coil. The kit consists of a valve, actuator and relative hydraulic ttings, it
is suitable for installation on both fan coils with hydraulic connections
on the right and left.
BCV: Condensate drip.
Installation accessories
MZC: Plenum with motorised dampers.
RDA_V: Straight intake connection with rectangular ange.
RPA_V: Suction plenum with rectangular ange; both sides have a cir-
cular push-out Ø 150mm that can be removed.
PA_V: Suction plenum with circular plastic anges; both sides have a
circular push-out Ø 150mm that can be removed.
PM_V: Internally insulated delivery plenum with circular anges; both
sides have a circular push-out Ø 150mm that can be removed.
RPM_V: Internally insulated delivery plenum with rectangular ange;
both sides have a circular push-out Ø 150mm that can be removed.
KFV10: Circular anges kit for plenum.
ACCESSORIES COMPATIBILITY
Control panels and dedicated accessories
Model Ver 430 432 440 441 530 532 540 541 630 632 640 641 730 732 740 741
AER503IR (1) . • • • • • • • • • • • • • • • •
PRO503 . • • • • • • • • • • • • • • • •
SA5 (2) . • • • • • • • • • • • • • • • •
SIT3 (3) . • • • • • • • • • • • • • • • •
SIT5 (4) . • • • • • • • • • • • • • • • •
SW3 (2) . • • • • • • • • • • • • • • • •
SW5 (2) . • • • • • • • • • • • • • • • •
TX (1) . • • • • • • • • • • • • • • • •
WMT05 . • • • • • • • •
WMT06 . • • • • • • • • • • • • • • • •
ACCESSORIES
