42
IVEDITI 4880981_03-2106
DIP SWITCHES
1 - 2 - 3 - 4
VED 0-1-2 I
DIP SWITCHES
1 - 2 - 3 - 4
VED 3 5 7 I
In ducted installations, to allow adjusting the
static pressure provided by the fan coil to
the pressure drops of the same duct, it is
possible to increase the
maximum speed in the VED I fan coils. To
increase fan speed, modify the settings of
the dip switches located on the VED I
motor and driver.
Attention!: Follow the settings indicated in
the table for each size of VED I.
