50
IVEDITI 4880981_03-2106
• RDA_V: Straight fitting with rectangular
flange for ducting.
In galvanised sheet steel
• RPA_V: Intake plenum with rectangular
flange for ducting.
In galvanised sheet steel
• PA_V: Intake plenum with circular flanges for
ducting.
In galvanised sheet steel, the flanges are in plas-
tic
• Flow plenum with rectangular flange
for ducting.
In galvanised sheet steel, internally isolated.
• Flow plenum with circular flanges for
ducting
In galvanised sheet steel, internally isolated, the
flanges are in plastic
•
• KFV: Circular flange kit for intake/flow
plenum.
In plastic
• VCF4_C: Kit made up from motorised 3-way
valves with isolating shell, fittings and
isolated copper pipes. For main coils.
230V~50 Hz power supply
• VCF4_H: Kit made up from motorised 3-way
valves, fittings and isolated copper pipes. For
heating only coils. 230V~50 Hz power
supply
• VCF25C - VCF25CS: Kit made up from motorised
2-way valves, with fittings and isolated copper
pipes. For main coils. 230V~50 Hz power supply
• VCF25H: Kit made up from motorised 2-way
valves, with fittings and copper pipes.
For heating only coils. 230V~50 Hz power supply
CONTROL PANELS
The complete features of the control panels are
described in the dedicated sheet.
Some control panels require coupling with other
accessories, consult the relative
documentation.
ACCESSORIES TO COUPLE WITH THE
CONTROL PANELS
• SIT3 : Thermostat interface board
Mandatory accessory on the VED units
coupled to thermostats different to the VMF
System
• SIT5: Thermostat interface board.
Allows to realise a network of VED units
• SW3: Water minimum temperature probe to use
with PXAE control panel.
The complete fittings of the VMF
System management system are described in
the dedicated sheet.
Some VMF components require coupling with
other accessories, consult the relative
documentation.
• Thermostat Interface Board
VMF. Mandatory accessory on the VED unit sup-
plied with VMF-E0 / E1 thermostat.
530I 532I 540I 541I 730I 732I 740I 741I
RDA 450 V
• • • •
RDA 670 V
• • • •
RPA 450 V
• • • •
RPA 670 V
• • • •
PA 450 V
• • • •
PA 670 V
• • • •
• • • •
• • • •
• • • •
• • • •
• • • •
KFV
• • • • • • • •
VCF45C
• • • •
VCF45H
• •
VCF47C
• •
VCF47CS
• •
VCF47H
• •
VCF25C
• • • • • •
VCF25CS
• •
VCF25H
• • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
