IVEDPY 1902 - 4460510_00
Manufactured with superior quality materials, in strict compliance with safety standards, the
VED is easy and durable in use.
The VED fan coil series is designed to be integrated into the VMF system.
VMF (Variable Multi Flow) is the system capable of controlling in an intelligent way a complete
hydronic installation composed of a chiller/heat pump, a boiler, a network of fan coil units
(multi-speed or continuous speed modulation) divided into zones (up to 64), the circulating
pumps (up to 12) and the heat recovery units with air quality sensors (up to 3), optimising
the performance in air-conditioning and heating, ensuring comfort and energy savings.
INDEX
IMPORTANT INFORMATION AND MAINTENANCE
18
PACKAGING 18
USE 18
UNIT DESCRIPTION 19
SYSTEM EXAMPLES 20
MAIN COMPONENTS 20
COMPONENT DESCRIPTION 21
INSTALLATION INFORMATION 23
ROTATING THE COIL 26
TECHNICAL DATA 27
COOLING CAPACITY 28
PRESSURE DROPS COOLING ONLY 40
2-PIPE SYSTEM PRESSURE DROPS HEATING ONLY
40
4-PIPE SYSTEM PRESSURE DROPS HEATING ONLY
40
FLOW STATIC PRESSURE 41
CORRECTION FACTORS IN FUNCTIONING
WITH GLYCOL WATER 45
IN COOLING MODE 45
GLYCOL WATER AT 10% 45
GLYCOL WATER AT 20% 45
GLYCOL WATER AT 35% 45
IN HEATING MODE 45
SOUND POWER LEVEL EXPRESSED IN DB (A) 46
WIRING DIAGRAMS 49
