AERMEC VED - Page 24

24
IVEDPY 1902 - 4460510_00
2. POWER YIELDED WITH HEATING ONLY COIL 4 PIPES AND 4 CONNECTIONS
The power yielded by the heating only coils installed on the fan coils (double-circuit or BV accessory), are stated in table format and are
referred to the maximum speed, based on the water flow and on the difference of temperature between water entering and air entering.
The performances at medium and minimum speed are obtained by multiplying the values in the graphic by the corrective factors indicated
for each speed.
NB: The yield values marked in bold indicate the nominal value.
Key:
Tw [°C] = Inlet water temperature
Ta D.B. [°C] = Inlet water temperature with dry bulb
Ph [w] = Heating power yielded
H = maximum speed
M = medium speed
L = minimum speed
The heating power yielded indicated in the table must be multiplied by the following corrective factors:
VED030 BV030 VED130 BV130 VED230 BV230 VED330 BV162
Total cooling capacity corrective values
H 1 1 1 1
M 0.94 0.95 0.93 0.93
L 0.72 0.78 0.82 0.83
VE130
BV130
Ta D.B. [°C]
16 18 20 22 24
Tw [°C] Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 3435 3257 3079 2906 2733
10 4142 4800 3780 3602 3424
15 4028 3845 3664 3483 3308
60
5 3559 3378 3195 3016 2838
10 3327 3149 2973 2798 2625
15 3195 3016 2838 2660 2485
50
5 2628 2453 2280 2110 1943
10 2507 2331 2156 1983 1810
15 2347 2167 1986 1805 1624
40
5 1816 1646 1479 1309 1144
10 1667 1489 1314 1136 952
15 1446 1249 1012 658 378
VED030
BV030
Ta D.B. [°C]
16 18 20 22 24
Tw [°C] Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 2017 1913 1808 1707 1605
10 2432 2819 2220 2115 2011
15 2366 2258 2152 2046 1943
60
5 2090 1984 1876 1772 1667
10 1954 1849 1746 1643 1542
15 1876 1772 1667 1562 1459
50
5 1543 1440 1339 1239 1141
10 1472 1369 1266 1165 1063
15 1379 1272 1166 1060 954
40
5 1066 967 868 769 672
10 979 875 772 667 559
15 849 734 594 387 222
VED330
BV162
Ta D.B. [°C]
16 18 20 22 24
Tw [°C] Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 5350 5073 4795 4526 4257
10 6451 7477 5888 5611 5333
15 6275 5989 5707 5426 5153
60
5 5543 5262 4976 4699 4421
10 5182 4905 4631 4358 4089
15 4976 4699 4421 4144 3871
50
5 4093 3820 3551 3287 3026
10 3904 3631 3358 3089 2820
15 3656 3375 3093 2812 2530
40
5 2828 2564 2303 2038 1782
10 2597 2320 2047 1769 1484
15 2253 1946 1576 1025 588
VED230
BV230
Ta D.B. [°C]
16 18 20 22 24
Tw [°C] Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 4083 3871 3659 3454 3249
10 4923 5705 4493 4281 4070
15 4788 4570 4355 4140 3932
60
5 4230 4015 3797 3585 3374
10 3954 3743 3534 3326 3120
15 3797 3585 3374 3162 2954
50
5 3124 2915 2710 2508 2309
10 2979 2771 2562 2357 2152
15 2790 2575 2360 2145 1931
40
5 2158 1956 1757 1555 1360
10 1982 1770 1562 1350 1132
15 1719 1485 1203 783 449
