AERMEC VED - Page 67

10
IVEDPY 2005 - 4879010_04
TECHNICAL DATA
VED for 2-pipe systems VED 430 440 530 540 630 640 730 740
Heating
Heating output 50°C
Rated W 10420 11950 11340 13110 18220 19600 20060 21820
Maximum (E) W 9475 10740 10420 11820 16070 17930 17280 19150
Average (E) W 8250 9130 9775 11050 13500 14940 15120 16680
Minimum (E) W 6195 6810 8190 9170 11100 11980 12640 13840
Pressure drop 50°C
Rated kPa 17 24 19 29 57 37 69 43
Maximum (E) kPa 13 19 16 23 48 32 57 35
Average (E) kPa 11 15 15 21 36 24 44 28
Minimum (E) kPa 7 9 11 16 26 17 33 21
Cooling
Cooling capacity
Rated W 8010 9290 8660 10280 13900 16450 15360 18100
Maximum (E) W 6950 8010 7760 8970 12530 15180 13850 16080
Average (E) W 6150 7060 7395 8545 10700 12760 12200 14230
Minimum (E) W 4685 5340 6160 7435 8890 10430 10400 11960
Sensible cooling capacity
Rated W 6225 6675 6755 7255 11500 11590 12770 12800
Maximum (E) W 5360 5735 6020 6450 10300 10660 11440 11320
Average (E) W 4715 5040 5715 6130 8750 8910 9990 9970
Minimum (E) W 3545 3785 4720 5040 7220 7240 8480 8340
Water flow rate
Rated l/h 1378 1598 1490 1768 2391 2829 2642 3113
Maximum l/h 1195 1378 1335 1543 2155 2611 2382 2766
Average l/h 1058 1214 1272 1470 1840 2195 2098 2448
Minimum l/h 806 918 1060 1279 1529 1794 1789 2057
Pressure drop
Rated kPa 22 30 26 37 58 47 70 56
Maximum (E) kPa 17 22 21 28 48 41 58 45
Average (E) kPa 13 17 19 25 36 30 46 37
Minimum (E) kPa 8 10 12 19 26 21 35 27
Common data
Air flow rate
Rated
cu.
m.
/h 1520 1520 1700 1700 2450 2450 2800 2800
Maximum (E)
cu.
m.
/h 1350 1340 1520 1500 2210 2200 2410 2350
Average (E)
cu.
m.
/h 1130 1100 1400 1380 1800 1770 2040 2000
Minimum (E)
cu.
m.
/h 790 780 1120 1100 1380 1370 1640 1600
Useful static head
(with filter installed)
Rated Pa 55 50 40 35 68 63 47 37
Maximum (E) Pa 72 70 70 56 75 75 69 69
Average (E) Pa 50 50 50 50 50 50 50 50
Minimum (E) Pa 24 24 25 32 30 30 32 32
Motor speed connections
Rated V5 V5 V5 V5 V5 V5 V5 V5
Maximum (E) V5 V5 V5 V5 V5 V5 V5 V5
Average (E) V3 V3 V4 V4 V3 V3 V3
V3
Minimum (E) V1 V1 V2 V2 V2 V1 V1 V1
Number of fans no. 2 2 2 2 3 3 3 3
Input power
Rated W 238 240 283 282 376 376 411 411
Maximum (E) W 228 222 270 267 339 339 371 371
Average (E) W 182 178 232 230 268 268 285 285
Minimum (E) W 137 135 175 172 224 224 234 234
Input power Maximum head W 290 290 300 300 436 436 440 440
Maximum input current A 1,4 1,4 1,35 1,35 2,07 2,07 2,0 2,0
Sound power level emitted by
the delivery of the unit
Maximum (E) dB(A) 57.2 57.3 58 58 64 68 64,5 64,5
Average (E) dB(A) 54 54 56 56 60,5 64 62 62
Minimum (E) dB(A) 45,5 46 51 51 55,5 59 58 58
Sound power level emitted by
the unit and by the air intake
side.
Maximum (E) dB(A) 61,5 61,5 62 62 68 64 68,5 68,5
Average (E) dB(A) 57,5 57,5 59,5 59,5 64,5 60 66 66
Minimum (E) dB(A) 51 51 53.5 53.5 59.5 55 62 62
Coil water content l 2,82 3,76 2,82 3,76 4,38 5,84 4,38 5,84
Coil connections diam 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G
Cooling:
• External air temperature 27°C D.B. ; 19°C W.B.
• Water inlet temperature 7°C ; Dt water 5°C
• Constant water flow rate
Heating:
• External air temperature 20°C
• Water inlet temperature: 50°C; Maximum speed
• Water flow rate as for cooling
The performance refers to the following conditions:
 Sound pressure measured in semi-reverberating chamber, 85m
3
, and
with reverberation time Tr = 0.5s.
MPS = 230V-1-50Hz
Unit with standard filter G3 installed
(E) = Performance certified EUROVENT 6/9 - Sound tests certified EUROVENT 8/12 (ISO 3741/2001)
