COOLING CAPACITY - VED740 / VED741
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 6097 6097 7613 7613 9084 9084 10522 10522 11961 11961 12674 12674
17 8317 6057 8617 7625 9265 9212 10548 10548 11987 11987 12699 12699
19 12933 6110 12907 7600 12881 9072 12894 10565 13166 12097 13322 12858
21 17780 7573 17742 9062 17704 10535 17666 12004 17648 12729
23 22963 8989 22907 10473 22869 11957 22831 12686
5
15 4976 4976 6667 6667 8254 8254 9784 9784 11274 11274 12013 12013
17 5727 4881 6946 6687 8267 8267 9797 9797 11300 11300 12039 12039
19 10211 5045 10237 6538 10548 8111 11131 9750 11896 11397 12324 12205
21 15499 6687 15473 8172 15473 9652 15473 11130 15551 11896
23 20833 8170 20833 9668 20758 11129 20758 11871
7
15 2913 2913 5235 5235 7101 7101 8773 8773 10367 10367 11144 11144
17 2919 2919 5261 5261 7114 7114 8799 8799 10393 10393 11157 11157
19 4820 3010 6660 5076 8047 6966 9330 8786 10587 10521 11235 11235
21 12051 5407 12077 6897 12440 8484 13010 10131 13347 10954
23 18194 7195 18175 8675 18157 10151 18119 10870
13
3
15 4535 4535 6090 6090 7587 7587 9045 9045 10483 10483 11196 11196
17 4898 4532 6103 6103 7606 7606 9058 9058 10509 10509 11222 11222
19 8915 4551 8889 6014 9110 7548 9641 9128 10535 10535 11248 11248
21 13840 6064 13814 7541 13788 9000 13762 10459 13827 11214
23 19024 7500 19005 8984 18948 10444 18929 11172
5
15 3082 3082 5028 5028 6686 6686 8254 8254 9771 9771 10522 10522
17 3095 3095 5034 5034 6699 6699 8267 8267 9797 9797 10548 10548
19 4846 3027 6077 4862 7257 6647 8436 8365 9810 9810 10561 10561
21 11041 5044 11041 6520 11274 8049 11766 9657 12051 10459
23 16611 6631 16573 8096 16535 9553 16535 10287
7
15 1471 1471 2939 2939 5351 5351 7153 7153 8812 8812 9602 9602
17 1471 1471 2939 2939 5351 5351 7179 7179 8825 8825 9615 9615
19 1517 1414 2952 2952 5416 5416 7192 7192 8838 8838 9641 9641
21 5598 3149 7179 5081 8501 6917 9719 8710 10289 9578
23 13114 5425 13114 6889 13373 8438 13581 9231
15
3
15 2900 2900 4542 4542 6077 6077 7561 7561 9006 9006 9732 9732
17 2906 2906 4548 4548 6090 6090 7581 7581 9032 9032 9745 9745
19 4237 2809 5125 4492 6194 6173 7593 7593 9045 9045 9771 9771
21 9537 4512 9511 5960 9667 7469 10095 9029 10393 9812
23 14812 6004 14799 7469 14747 8913 14734 9637
5
15 1177 1177 3187 3187 5060 5060 6699 6699 8254 8254 9019 9019
17 1180 1180 3187 3187 5066 5066 6712 6712 8267 8267 9032 9032
19 1186 1186 3213 3213 5079 5079 6725 6725 8293 8293 9045 9045
21 5313 3056 6453 4831 7568 6580 8682 8292 9252 9133
23 11870 5011 11870 6465 12013 7967 12194 8749
7
15 233 233 1471 1471 3056 3056 5429 5429 7205 7205 8034 8034
17 233 233 1471 1471 3056 3056 5442 5442 7218 7218 8047 8047
19 233 233 1471 1471 3069 3069 5455 5455 7231 7231 8060 8060
21 1525 1390 3161 3137 5611 5469 7295 7295 8086 8086
23 6298 3221 7749 5077 8993 6865 9589 7745
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 740/741
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 2800 1 1
Maximum speed 2350 0.89 0.88
Average speed 2000 0.79 0.79
Minimum speed 1600 0.66 0.65
COOLING CAPACITY CORRECTION FACTORS
