5. BARYCENTRE
WRL
Total weight
(machine
working)
Gx Gy
Support A
[kg]
Support B
[kg]
Support C
[kg]
Support D
[kg]
180 398 412 562 109.5 116.4 83.4 88.7
200 398 412 562 109.5 116.4 83.4 88.7
300 406 409 568 111.7 116.7 86.7 90.6
400 413 412 562 113.5 120.5 86.6 91.9
500 548 388 1005 140.5 132.2 142.0 133.6
550 624 387 944 170.2 159.6 152.0 142.6
600 706 386 953 190.9 178.4 173.9 162.5
650 751 386 916 210.4 196.4 177.9 166.1
A B
C
A
G
G
Gy
Gx Gx
Gy
C
D
B
D
WRL 180 / 400
WRL 500 / 650
