3-3-5. BUMPER REPLACEMENT
DESCRIPTION
This procedure is used to replace the bumper(s) on the 3500 / 3500A.
REMOVE
Fully loosen the captive screws on each side of the bumper and remove the bumper from the
3500 / 3500A.
INSTALL
Install the bumper on the 3500 / 3500A and tighten the captive screws (on each side of the
bumpers) (8 in/lbs.).
