4-6 Subject to Export Control, see Cover Page for details.
4-3-2. SPECTRUM ANALYZER SCREEN FEATURES AND FUNCTIONS (cont)
SCREEN FEATURE FUNCTION
F1 “Edit” / “Done” / “Next” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Next Displays the next pop-up screen.
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Saves the test screen.
F3 “Hold” / “Resume” /
“Find”
Hold Freezes the screen.
Resume Restores the screen to active mode.
Find Used to perform the Frequency Find function.
F4 “Norm” / “Abort” Norm Instruction pop-ups are displayed to normalize the
Spectrum Analyzer.
Abort Aborts the normalize sequence.
F5 “Control” / “Marker” /
“PBw” / “Esc”
Control Used to change the displayed fields and functionality on
the Spectrum Analyzer Screen to Control Mode.
Marker Used to change the displayed fields and functionality on
the Spectrum Analyzer Screen to Marker Mode.
PBw Used to change the displayed fields and functionality on
the Spectrum Analyzer Screen to Power Bandwidth Mode.
Esc Ends the Field Edit, but does NOT save any changes to the
setting or value.
Edit Norm Ho l
d
Ma rke r Re tur
n
(when accessed from the Mini-Meter)
SCREEN FEATURE FUNCTION
F1 “Edit” / “Done” / “Next” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Next Displays the next pop-up screen.
F2 “Norm” / “Save” Norm Instruction pop-ups are displayed to normalize the
Spectrum Analyzer.
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
