4-7-2. DMR MINI METER FEATURES AND FUNCTIONS
DMR Demod More
Fr eq Err -4 .4
FSK Err 3.3
Sym Dev 1947
Ma g E rr 0. 41
DMR Demod More
Pat tern 1031
BER 3.2 41
Slot1 Pwr -25.0
Slot2 Pwr -6.4
DMR Demod More
Color 0
Call*ID 0
Rad. ID 167770 16
Reset Acq
SCREEN FEATURE FUNCTION
Freq Err Displays the frequency error of the transmitted signal.
FSK Err Displays the FSK Error of the transmitted signal.
Sym Dev Displays the symbol deviation accuracy.
Mag Err Displays the magnitude error.
Pattern Used to set the data or voice pattern.
Select: 1031, BR (Base Radio), 0.153 or CAL
BER Displays the incoming DMR symbol data compared to a standard
pattern in determining errors in signal processing.
Slot1 Pwr Displays the Slot1 power measurement.
Slot2 Pwr Displays the Slot2 power measurement.
Color Displays the Color Code.
Call ID Displays the Call Identification value.
Rad. ID Displays the Radio Identidication value.
Reset Acq Used to reacquire the input signal.
