4-8-2. NXDN MINI METER FEATURES AND FUNCTIONS
NXDN Demod More
Sig Pwr -1.9
Fr eq Err 4 .3
FSK Err 1.0
Sym Dev 1056
NXDN Demod More
BER 1.7 36
RAN 0
Rate 4800
Pat tern 1031
NXDN Demod More
Reset Acq
SCREEN FEATURE FUNCTION
Sig Pwr Displays the RF level at the input connector.
Freq Err Displays the frequency error of the transmitted signal.
FSK Err Displays the FSK Error of the transmitted signal.
Sym Dev Displays the symbol deviation accuracy.
BER Displays the incoming NXDN symbol data compared to a standard
pattern in determining errors in signal processing.
RAN Displays the Radio Access Number.
Rate Used to select the rate that data is transmitted.
Select: 4800 or 9600 bps
Pattern Used to set the data or voice pattern.
Select: 1031, 0.153 or CAL
Reset Acq Used to reacquire the input signal.
