4-11-6. SCRIPTING FLOWCHARTS (cont)
RECEIVER
:upconv ert er:fgen1:st ate *<*>
:upconverter:fgen1:freq *<*>
:upconverter:fgen1:fm *<*>
:upconv ert er:fgen2:st ate *<*>
:upconverter:fgen2:freq *<*>
:upconverter:fgen2:fm *<*>
:upconv ert er:dcs:state *<*>
:upconverter:dcs:am *<*>
:upconverter:dcs:fm *<*>
:upconv ert er:mic:state *<*>
:upconverter:mic:am *<*>
:upconverter:mic:fm *<*>
Gen1
Gen2
DCS
Mic
Upconverter
:upconverter:type *<*>
:upconv ert er:carrier_st ate *<*>
:upconverter:mod_inhibit *<*>
A
RF*Generator
:gen:freq *<*>
:gen:lvl:dbm *<*>
:gen:port *<*>
ANT
T/ R
SWR
:gen:port:protection *<*>
A
