C-4. REMOTE OPERATION COMMANDS (cont)
Oscilloscope
COMMAND RANGE DESCRIPTION
:scope:coupling 0 - AC
1 - DC
2 - GND
Sets Oscilloscope input coupling.
:scope:coupling? Returns Oscilloscope input coupling.
:scope:dvm:divby20 0 - 2 V max
1 - 40 V max
Sets input scaling for DVM Connector.
:scope:dvm:divby20? Returns input scaling for DVM Connector.
:scope:dvm:overload? 0 - No Overload
1 - Overload
Returns DVM overload status.
:scope:offset:horiz Sets Oscilloscope input horizontal offset.
:scope:offset:horiz? Returns Oscilloscope input horizontal offset.
:scope:offset:vertical -100.0 to 100.0 Sets Oscilloscope input vertical offset.
:scope:offset:vertical? Returns Oscilloscope input vertical offset.
:scope:scale:horiz
0 - 20 μs/Div
1 - 50 μs/Div
2 - 0.1 ms/Div
3 - 0.2 ms/Div
4 - 0.5 ms/Div
5 - 1 ms/Div
6 - 2 ms/Div
7 - 4 ms/Div
8 - 6 ms/Div
9 - 10 ms/Div
10 - 20 ms/Div
11 - 50 ms/Div
12 - 0.1 sec/Div
Sets Oscilloscope input horizontal scale.
:scope:scale:horiz? Returns Oscilloscope input horizontal scale.
:scope:scale:vertical 0 - 10 mV/Div (DVM / AUDIO IN)
0.1 kHz/Div (DEMOD FM)
5%/Div (DEMOD AM)
1 - 20 mV/Div (DVM / AUDIO IN)
0.2 kHz/Div (DEMOD FM)
10%/Div (DEMOD AM)
2 - 50 mV/Div (DVM / AUDIO IN)
0.5 kHz/Div (DEMOD FM)
20%/Div (DEMOD AM)
3 - 0.1 V/Div (DVM / AUDIO IN)
1 kHz/Div (DEMOD FM)
50%/Div (DEMOD AM)
4 - 0.2 V/Div (DVM / AUDIO IN)
2 kHz/Div (DEMOD FM)
5 - 0.5 V/Div (DVM / AUDIO IN)
5 kHz/Div (DEMOD FM)
6 - 1 V/Div (DVM / AUDIO IN)
10 kHz/Div (DEMOD FM)
7 - 2 V/Div (DVM / AUDIO IN)
20 kHz/Div (DEMOD FM)
8 - 5 V/Div (DVM / AUDIO IN)
50 kHz/Div (DEMOD FM)
9 - 10 V/Div (DVM / AUDIO IN)
Sets Oscilloscope input vertical scale.
:scope:scale:vertical? Returns Oscilloscope input vertical scale.
:scope:source 0 - DVM
1 - DEMOD
2 - AUD IN
3 - FGEN
Sets Oscilloscope input source.
:scope:source? Returns Oscilloscope input source.
