2-1. OPERATOR’S CONTROLS, INDICATORS AND CONNECTORS (cont)
Figure 2-2. Comm Breakout Box Connectors
CONNECTOR FUNCTION
USB HOST Connector Used to connect to external unit.
RS-232 Connector Used to connect to RS-232 external unit.
ETHERNET Connector Used to connect to an external unit.
REMOTE Connector Used for communicate with the 3500 / 3500A.
