Subject to Export Control, see Cover Page for details. 2-17
A. Duplex Test Screen (cont)
SCREEN FEATURE FUNCTION
Modulation Meter Used to select the position of the Modulation Meter on the Duplex
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 6, 8 or 9
RSSI Meter Used to select the position of the RSSI Meter on the Duplex Test
Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 6, 8 or 9
RF Error Meter Used to select the position of the RF Error Meter on the Duplex Test
Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 6, 8 or 9
RF Power Meter Used to select the position of the RF Power Meter on the Duplex
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 6, 8 or 9
SINAD Meter Used to select the position of the SINAD Meter on the Duplex Test
Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 6, 8 or 9
Distortion Meter Used to select the position of the Distortion Meter on the Duplex
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 6, 8 or 9
AF Counter Used to select the position of the AF Counter on the Duplex Test
Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 6, 8 or 9
DTMF Decode Used to select the position of the DTMF Decode Meter on the Duplex
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 6, 8 or 9
DCS Decode Used to select the position of the DCS Decode Meter on the Duplex
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 6, 8 or 9
Audio Level Used to select the position of the Audio Level Meter on the Duplex
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 6, 8 or 9
Meter Chart Displays the areas of the Duplex Test Screen and a number
representing each area (i.e., 3 is top right on the Duplex Test
Screen, etc.).
F1 “Edit” / “Done” / “Zoom Edit Highlights the selected field to be changed.
Done Ends the Field Edit and saves the new setting / value.
Zoom Displays the screen of the field selected.
F2 “Return” Displays the Duplex Test Screen.
F5 “Esc” Ends the Field Edit, but does NOT save any changes to the setting
or value.
