Aeroflex 3500A - Page 61

Subject to Export Control, see Cover Page for details. 2-21
B. Receiver Test Screen (cont)
SCREEN FEATURE FUNCTION
Dcs Used to select the DCS state.
Select: AM:
Inv (Interted), NonInv (Non-Inverted) or Off
DCS Code 023, 025, 026, 031, 032, 043, 047, 051, 054,
065, 071, 072, 073, 074, 114, 115, 116, 125,
131, 132, 134, 143, 152, 155, 156, 162, 165,
172, 174, 205, 223, 226, 243, 244, 245, 251,
261, 263, 265, 271, 306, 311, 315, 331, 343,
346, 351, 364, 365, 371, 411, 412, 413, 423,
431, 432, 445, 464, 465, 466, 503, 506, 516,
532, 546, 565, 606, 612, 624, 627, 631, 632,
654, 662, 664, 703, 712, 723, 731, 732, 734,
743 or 754
%Mod 0% to 100% in 0.1% increments
Select: FM:
Inv (Interted), NonInv (Non-Inverted) or Off
DCS Code 023, 025, 026, 031, 032, 043, 047, 051, 054,
065, 071, 072, 073, 074, 114, 115, 116, 125,
131, 132, 134, 143, 152, 155, 156, 162, 165,
172, 174, 205, 223, 226, 243, 244, 245, 251,
261, 263, 265, 271, 306, 311, 315, 331, 343,
346, 351, 364, 365, 371, 411, 412, 413, 423,
431, 432, 445, 464, 465, 466, 503, 506, 516,
532, 546, 565, 606, 612, 624, 627, 631, 632,
654, 662, 664, 703, 712, 723, 731, 732, 734,
743 or 754
Dev kHz 0 to 100 kHz in 0.01 kHz increments
MIC Used to select the external Microphone and the level of modulation for
the microphone input.
Select: On The external Microphone modulates the test set
signal generator.
Off Deactivates the external Microphone input.
AM 0% to 100% in 0.1% increments
FM 0 to 100 kHz in 0.01 kHz increments
Ext Aud Used to select external modulation.
Select: On Permits an external tone generator to modulate
the test set signal generator.
Off Deactivates the external Audio input.
Load
Used to select the Audio input signal load (Ω ).
Select: 150, 600, 1K (3500A), Div10 (3500A) or High Z
