24
26
25
27
Make sure that left fuselage side R1 B fits perfectly on formers
before you glue. Make corrections as necessary.
Then glue in place left fuselage side on formers and glue R19
onto wing retainer R18.
Glue in place formers R9 and R10. Please note that bores for
elevator control are located in upper half of formers.
Secure with tape wrapped around fuselage.
Glue former R11 into rear of fuselage (bore for elevator control
faces up), glue together rear end of fuselage sides without
sanding reinforcements R13, R14. Secure with clamps.
Note: Width at rear end of fuselage must not be reduced.
Elevator control exits between fuselage sides.
Insert and glue R7/R8 into nose section, pulling together front of
fuselage sides. Glue in place motor mount R20 and secure with
clamps and tape.
i
R19
R1 B
R18
R11
R9
R10
R20
R7/R8
