Aerpro AM9XFW - Connect LCD to Head Unit

Step #3 Connecting the LCD to the Head Unit
• To connect the LCD to the unit, carefully push the LCD wiring harness into the LCD
connector of receiver's chassis as shown below.
• Use the hinge hooks on the back of the monitor to hold the LCD in place.
INSTALLATION
3
6
